Private MIB Parameters
Table C‐2: Private MIB Parameters (Sheet 19 of 32)
Name
winlink1000OduAgnCurrAlarmTable
winlink1000OduAgnCurrAlarmEntry
winlink1000OduAgnCurrAlarmCoun
ter
winlink1000OduAgnCurrAlarmSeve
rity
winlink1000OduAgnCurrAlarmId
winlink1000OduAgnCurrAlarmIfInd
ex
winlink1000OduAgnCurrAlarmUnit
winlink1000OduAgnCurrAlarmTrapI
D
winlink1000OduAgnCurrAlarmTime
T
winlink1000OduAgnCurrAlarmText
winlink1000OduAgnLastEventsNum
ber
winlink1000OduAgnLastEventsTable
winlink1000OduAgnLastEventsEntr
y
winlink1000OduAgnLastEventsInde
x
winlink1000OduAgnLastEventsSeve
rity
winlink1000OduAgnLastEventsIfInd
ex
winlink1000OduAgnLastEventsTime
T
winlink1000OduAgnLastEventsText
winlink1000IduAdmProductType
winlink1000IduAdmHwRev
winlink1000IduAdmSwRev
winlink1000OduAdmNumOfExterna
lAlarmIn
winlink1000OduAdmExternAlarmIn
Table
winlink1000OduAdmExternAlarmIn
Entry
winlink1000OduAdmExternAlarmIn
Index
RADWIN 2000 C Plus User Manual
OID Type
1.3.6.1.4.1.4458.1000.1.7.4. Integer
1
1.3.6.1.4.1.4458.1000.1.7.4. Integer
2.1.1
1.3.6.1.4.1.4458.1000.1.7.4. Integer
2.1.2
1.3.6.1.4.1.4458.1000.1.7.4. Integer
2.1.3
1.3.6.1.4.1.4458.1000.1.7.4. Integer
2.1.4
1.3.6.1.4.1.4458.1000.1.7.4. DisplayString
2.1.5
Release 3.5.70
Description
N/A This table includes the currently active alarms.
When a RAISED trap is sent an alarm entry
is added to the table. When a CLEAR trap is sent
the entry is removed.
N/A Entry containing the details of a currently
RAISED trap. INDEX {
winlink1000OduAgnCurrAlarmCounter }
RO A running counter of active alarms. The counter
is incremented for every new RAISED trap. It is
cleared after a device reset.
RO Current Alarm severity.
RO Unique Alarm Identifier (combines alarm type
and interface). The same AlarmId is used for
RAISED and CLEARED alarms.
RO Interface Index where the alarm occurred.
Alarms that are not associated with a specific
interface will have the following value: 65535.
RO Unit associated with the alarm.
RO ID of the raised trap that was sent when this
alarm was raised.
RO Timestamp of this alarm. This number is in
seconds from Midnight January 1st 1970.
RO Alarm display text (same as the text in the sent
trap).
RO This counter indicates the size of the
winlink1000OduAgnLastEventsTable
N/A This table includes the last events. When a trap
is sent an event entry is added to the table.
N/A Entry containing the details of last traps. INDEX
{ winlink1000OduAgnLastEventsIndex }
RO The index of the table
RO Current Trap severity.
RO Interface Index where the event occurred. Traps
that are not associated with a specific
interface will have the following value: 65535.
RO Timestamp of this trap. This number is in
seconds from Midnight January 1st 1970.
RO Trap display text (same as the text in the sent
trap).
RO IDU configuration description.
RO IDU Hardware Revision.
RO IDU Software Revision.
RO Indicates the number of currently available
External Alarm Inputs.
N/A This is the External Alarm Inputs table.
N/A Entry containing the elements of a single
External Alarm Input. INDEX {
winlink1000OduAdmExternAlarmInIndex}
RO This value indicates the index of the External
Alarm Input entry.
