4.0 Liebert IntelliSlot Unity Card Web Page Layout
Default settings in the Liebert IntelliSlot Unity card permit using it immediately after installation to monitor
the equipment the card is installed in. The Web interface permits customizing the information to ease
monitoring the equipment and troubleshooting problems. Users can name the equipment, enter a location,
set up email and text alerts and change equipment settings.
NOTE
The Edit button will be grayed-out if the settings on a menu cannot be changed.
4.1 Web Page Sections
Each Web page displayed by the Liebert IntelliSlot Unity card has these main areas (see Figure 4-1):
• Identification
• Status
• Tab Menus
• Detail
Identification
Displays the System Name, System Location and System Description
Status
Displays the status of the monitored equipment, the Liebert IntelliSlot Unity card and any Liebert SN
sensors connected to the card.
Tab Menus
The Liebert IntelliSlot Unity card has two tabs by default: the Managed Device tab, which will display the
name of the monitored equipment, and the Communications tab. A third tab, the Sensor tab, appears if
Liebert SN sensors have been installed. The tab selected determines the menu shown.
• Managed Device tab—Information pertaining to the equipment being monitored and controlled. Refer
to 4.3 - Managed Device Tab Menus for details. The tab label refers to the type of Liebert unit the
card is installed in. For example, the Managed Device tab for a card installed in a Liebert GXT4-1000-
RT120 UPS will be labeled GXT4-1000-RT120 (see Figure 4-1 for this example). Figure 4-2 shows a
Web page for a Liebert IntelliSlot Unity card installed in a Liebert CRV.
• Communications tab—Information about the Liebert IntelliSlot Unity card, such as the overall event
status of the equipment and communication interface, logs of third-party information, communication
settings, third-party protocol settings and system status. Refer to 4.4 - Communications Tab Menus
for details.
• Sensor tab—Information about Liebert SN sensors, if any are installed, including status or data from
each sensor and sensor configuration settings. When sensors are connected to the card, this tab
appears between the Managed Device tab and the Communications tab. The tab is not shown when
no sensors are connected to the card (see Figure 4-3). Refer to 4.5 - Sensor Tab Menus—Shown
Only if a Sensor is Connected for details.
