Display Overview
Figure 2-3 illustrates some of the key information areas of the MS2711D display.
SWEEP
MODE
DETECTION
METHOD
PREAMPLIFIER
STATE
Figure 2-3.
Display Overview
Figures 2-4 through 2-12 illustrate the menu structures and soft key labels for each menu
selection. Refer to Chapter 3, Key Functions, for more detailed hard and soft key descrip-
tions.
TITLE BAR
MESSAGE AREA
Chapter 2 Quick Start Guide
CURRENT
MENU
2-3
