Chapter 6 Power Measurement
Recall an Offset Calibration
The offset calibration will be turned off when the system is rebooted. However, the last cal-
ibration is always saved and can be recalled and applied again without performing another
calibration.
Step 1. Press the Amplitude key.
Step 2. Press the Offset dB soft key.
Step 3. Press the Recall Offset CAL soft key.
Turn Off an Offset Calibration
The Offset Calibration can be turned off by rebooting the Spectrum Master. To turn off the
Offset CAL without rebooting the instrument:
Step 1. Press the Amplitude key.
Step 2. Press the Offset dB soft key.
NOTE: The Offset Calibration can be applied to the Amplitude Offset in Spec-
trum Analyzer and Interference Analyzer modes. For Power Meter, Spectrum
Analyzer, or Interference Analyzer mode, the average insertion loss value of the
span will be shown.
6-6
