Attenuator Functions
Attenuation adjusts the hand held spectrum analyzer input attenuator. In Auto mode, as the
reference level is increased, the attenuation is increased. In Manual mode, the input attenu-
ation can be adjusted using the keypad or the Up/Down arrow key. The attenuator range is
0 to 51 dB, in 1 dB steps. When Dynamic attenuation is selected, the instrument automati-
cally sets the input attenuation and preamplifier to achieve the best possible dynamic range
(See page 5-22).
IMPORTANT! Attenuation is normally a coupled function and is automatically
adjusted when the reference level changes. The reference level does not
change however, when the attenuator changes. The attenuator should be ad-
justed so that the maximum signal amplitude at the input mixer is –25 dBm or
less. For example, if the reference level is + 20 dBm, the attenuation should be
50 dB for an input signal of –25 dBm at the mixer (+20 – 45 = –25). This pre-
vents signal compression. The nominal gain of the preamplifier is +25 dB,
therefore always select attenuation values so that the input to the preamp does
not exceed –50 dBm.
NOTE: It is best to begin all measurements in AUTO attenuation mode.
