Chapter 2: Jumpers and Connectors

GAL Programmer Connector

Connector size: 1x6 6-pin header, 2.54 mm
Connector location: JP4
6
1
Pin Definition
1 VCC3_3
2 GND
3 TCK
4 TDO
5 TDI
6 TMS
Copyright © 2011 NEXCOM International Co., Ltd. All rights reserved

MCU Programmer Connector

Connector size: 1x5 5-pin header, 2.54 mm
Connector location: JP1
1 5
Pin Definition
1 +3.3ALW
3 MRST
5 GND
22
Pin Definition
2 C2D
4 C2CK
