Display Of Messages In Zone 4 - SDMO R33C3 User And Maintenance Manual

Screen No.
P10
P11
Order of appearance of screens based on the type of network with the genset started.
Order of appearance
1
2
3
4
5
6
7
The screen is changed using the scrolling and validation wheel.
When the wheel is turned clockwise, the screens scroll upwards and backwards.
The screens scroll in a loop.
Example: in a 3P+N network after screen 7, then screen 1 and in reverse.

Display of messages in zone 4

6.3.1.6.
The graphic zone (zone 4) is used to display messages relating to the generating set's operation. These messages are as follows:
Initialisation of the TELYS
Screen No.
G 1
SERIAL No.: 08030010000
SOFTWARE: 6.1.0
NOMINAL VOLTAGE: 400V
FREQUENCY: 50Hz
G 2
NOMINAL KW: 320kW
EARTH SYSTEM: TNS
Pictograms
3P+N
P3 if genset started P3 if genset
P11 if genset
coupled P11 if genset
P4
P5
P8
P9
P2
P10
Screen
Fuel Level Indication
Battery Voltage indication
Battery Ammeter Indication
Total Reactive Power Indication
Alternator U12 compound Voltage Indication
Total Active Power Indication
Alternator Frequency Indication
Type of line
3P 2P+N
P3 if genset started
started P11 if genset
coupled
coupled
P4 P6
P8 P8
P9 P9
P2 P2
P10 P10
Initialisation of the TELYS when switching on and/or
when loading a configuration
Generating set serial number
TELYS software version
Alternator nominal voltage
Alternator nominal frequency
Nominal active power
Neutral speed
Bar graph indicating the screen display time
71/242
Data displayed
1P+N
P3 if genset started
P11 if genset
coupled
P7
P9
P2
P10
Data displayed
