4-3-10

Using the CD-RW / MOD (Magneto-Optical Drive)

4-3-10-1 Using the CD-RW
Never move the unit with a disk in the CD-RW because the drive actuator will not be locked
NOTICE
and the CD-RW could break.
1.) Push the EJECT button, the disk tray will appear.
2.) Put the disk onto the disk tray.
3.) Press the EJECT button to insert the disk into the CD-RW device.
4.) There are a number of methods to eject a disk from the CD-RW. Ejection is automatic in some
cases. Manual ejection methods, listed in preferred order of use, are:
a.) Press EJECT button on the CD-RW while system is ON.
b.) Press and hold EJECT button while the system is booting.
c.) Mechanical ejection. Insert the end of a paper clip into the hole next to the EJECT button while
Avoid mechanical ejection whenever possible. Mechanical ejection leaves the actuator
NOTICE
unlocked and the MOD susceptible to damage if moved. If forced to use this method, reboot
the system, then insert and eject a known good disk using one of the other methods.
Eject Button
4 - 14
7
system power is OFF.
CD-RW Drive
Figure 4-30 CD-RW drives
