Table 5-4
Signal Name
(Pin No)
Red Out (1)
Green Out(3)
Blue Out(5)
CSYNC(7)
BW Out 1(11)
BW Out 2(41)
SVHS Y Out((16)
SVHS C Out((18)
Comp Out(20)
SVHS Y In(22)
SVHS C In(37)
Comp In(24)
BW Shutter 1
BW Shutter 2
VGA R(31), G(33),
B(35), HS(39),
VS(26)
DC12V(13)
DC5V(15, 30)
5-20
7
Connector J2 (Peripheral Interface I/O)
Description
Analog Red out signal for Color printer
Analog Green out signal for Color printer
Analog Blue out signal for Color printer
Composite Sync Signal for Analog Color Printer
Analog Video signal output to BW Printer for Front BW
printer
Analog Video Signal Output to BW Printer in Rear
Panel
Y Signal Output for S VHS recording
C Signal Output for S VHS recording
Composite Video Output for VCR recording
Y Signal Input for S VHS Playback
C Signal Input for S VHS Playback
Video Composite Input for VCR Playback
Shutter Signal Out for BW Printer on Front
Shutter Signal Out for BW Printer on Rear
VGA Signal for External VGA Monitor Port in Rear
Panel
DC 12Volt Power for Isolation Circuit and Switch
Circuit for Speaker Sound in Rear Panel
DC 5Volt Power for EEPROM in Rear Panel
