7462
MB790 paper path rolls and sensors
PC drum
Sensor (input)
PC cartridge
Sensor (option
pass through)

Functions of main components

•
Media tray assembly
•
Pic arm assembly (feed)
•
MPF
•
Xerographics
•
Transfer
•
Fuser
•
Drive
•
Electrical components and rolls
Media tray assembly
It is necessary to adjust the media tray rear guide and media tray side guide of the media tray assembly to
match the media size.
3-44
Service Manual
Standard bin full actuator
and sensor (standard bin full)
Diverter
Sensor (fuser output)
Sensor (narrow media)
Sensor
(duplex input)
Pick arm
assembly
