Special Adapter - Mitsubishi Electric FX3G User Manual

FX /FX /FX /FX /FX
3S 3G 3GC 3U
Common Items
2.1.2

Special adapter

The analog special adapter uses PLC devices to send/receive data to/from the PLC.
1. FX Series PLC
3S
• Connect the special adapter to the left side of the FX
• A connector conversion board is needed to connect the special adapter.
*1
• Only 1 analog special adapter can be connected.
Analog
special adapter
Only 1 analog adapter can be connected.
*1. When special adapter is connected to FX
the main unit.
2. FX Series PLC
3G
• Connect the special adapter(s) to the left side of the FX
• A connector conversion board is needed to connect the special adapter(s).
*2
• Up to 2 analog special adapters can be connected.
Analog
special adapters
Up to 2 analog adapters can be connected.
*2. Only 1 analog special adapter can be connected to the FX
In this case, expansion boards cannot be used.
When two analog special adapters are connected to FX
analog expansion boards cannot be connected to the main unit.
A-6
PLC User's Manual - Analog Control Edition
3UC
Connector conversion adapter
FX -CNV-ADP
3S
Connector conversion adapter
FX -CNV-ADP
3G
Series PLC.
3S
PLC
→ For a detailed description of the system configuration,
refer to the FX Series User's Manual - Hardware Edition.
3S
Series PLC, expansion boards cannot be connected to
3S
Series PLC.
3G
PLC
→ For a detailed description of the system configuration,
refer to the FX Series User's Manual - Hardware Edition.
3G
Series PLC (14-point and 24-point type).
3G
Series PLC (40-point or 60-point type),
3G
2 Description of Analog Products
2.1 Types of Analog Products
