Chapter 1—Introduction
Product Description
In addition, the EGX200 contains a web server, which lets you remotely configure and
troubleshoot both Ethernet and serial communication parameters. A typical application
example is shown in Figure 1–1.
MODBUS
TCP/IP
Sepam 1000
PowerLink G3
Figure 1–1:
2
POWERLOGIC
System Manager
ETHERNET
®
EGX200
+
Series 20
Enercept Meters
panelboard
System architecture example showing EGX200 installed for
Ethernet connectivity
®
Modicon
Quantum PLC
with NOE Card
Circuit Monitor
