RS-232 Serial Port

RS-232 is used to configure the EGX200 network parameters, and also can be used
for serial communication using Modbus RTU. The EGX200 RS-232 port uses a
standard DB9 male connector. The following table shows the typical serial RS-232
connector pinout.
Table 4–3: RS-232 Pin Assignments (DB9 EGX200 Signal Set)
Pin No.
Pin 1
Pin 2
Pin 3
Pin 4
Pin 5
Pin 6
Pin 7
Pin 8
Pin 9

COM 1 and COM 2 LEDs

One set of LEDs is provided for each COM port. A yellow LED illuminates when the
corresponding COM port is receiving data (Rx). A green LED illuminates when data on
the corresponding COM port is transmitted (Tx). Also, above the COM 2 Rx and Tx
LEDs, a third LED (green) illuminates steadily when COM 2 is selected to be active for
RS-485 communication. The COM 2 Tx and Rx LEDs behave the same way when
used for either RS-485 or RS-232 communication.
© 2001 Schneider Electric All Rights Reserved
Received Line Signal Detector (Data Carrier Detect)
Received Data
Transmit Data
Data Terminal Ready
Signal Ground
Data Set Ready
Request To Send
Clear To Send
Ring Indicator
