APPENDIX C—
This appendix provides instructions for using System Manager Software (SMS) to set
up a PC interface with the EGX200.
NOTE: You must be running SMS version 3.2 or higher.
To communicate with SMS, follow these steps:
1. Launch SMS.
2. Open an existing system or create a new system.
3. Add a communication connection for the EGX200.
• For the communications connection name, type a unique name for your EGX200
connection.
• For the communications driver, select "MODBUS/TCP driver."
4. Input the EGX200 IP address in the communication connection (MODBUS/TCP).
5. After defining the communications connection, add the serial daisy-chained
devices using the EGX200 communication connection.
For more details about this process, please refer to the SMS Help option in SMS by
going to SMS > Quick Start > Quick start MODBUS/TCP device setup.
