Chapter 3—Getting Started
EGX200 Initial Setup
The Microsoft TCP/IP Properties dialog box displays, as shown in Figure 3–3.
Figure 3–3: Entering the IP Address and Subnet Mask
e. From the Microsoft TCP/IP Properties dialog box, select "Specify a IP address."
f. Enter the IP address (10.10.10.11) and subnet mask (255.255.255.0), and then
click OK.
g. Reboot your PC, if required.
4. Launch a standard web browser such as Internet Explorer.
5. In the browser address field (see Figure 3–4), type the EGX200 IP address
(10.10.10.10), and press Enter.
Figure 3–4: IP address entered in browser address field
