EGX200 Embedded Web Page Options
Table 5–3 shows the address range available for various protocols.
Table 5–3: RS-485 Device Definitions Address Range
Protocol
MODBUS, JBUS
POWERLOGIC
NOTES:
• Do not assign address 16 to any MODBUS or JBUS device if you have a mixed-
mode daisy chain (for example, a single daisy chain with some RS-485 devices
using POWERLOGIC protocol and other devices using MODBUS/JBUS protocol).
• Do not assign address 1 to any POWERLOGIC protocol device on a mixed-mode
daisy chain (for example, CM2000, CM100, CM200, 810 D, PIF85, PIF3, Digital
Relay, and POWERLINK AS).
• Do not use the same address for any two devices on the two ports.
• We recommend that you wire and connect all MICROLOGIC trip units to COM 1.
(Please refer to the MICROLOGIC Trip Unit instruction bulletin for proper
addressing.)
• By default, this page displays 16 slots to define devices. For information on
increasing the number of devices in the Device List page, see "Advanced Setup" on
page 38.
34
Available Device Address Range
1 through 247
1 through 199
