Chapter 5—Operation
EGX200 Embedded Web Page Options

Advanced Setup

The Advanced Setup page (Figure 5–8) is accessible by the administrator password
only. This page allows administrator level users to change EGX200 timing values that
normally should not be changed. Also, you can use this page to set the EGX200 on-
board clock. EGX200 parameters and corresponding values are shown in Table 5–5.
Figure 5–8: EGX200 Advanced Setup page
Table 5–5: Advanced communication setup parameters
Parameter
User Timeout
Timeout for COM
Ports
Number of
Viewable Devices
Default Language English, French, Spanish The language to be displayed as the default
Set Time

Logging Out

To log out of the EGX200 configuration session, click Home to return to the EGX200
Home page. Click Log Out to end your session.
38
Range of Values
1 to 255 minutes
3 to 10 seconds
2 to 96 devices
Description
Maximum idle time allowed before the EGX200
ends a user's access to the web pages
Maximum time the EGX200 waits for requested
information from RS-485 daisy-chained devices
Number of viewable devices in the Device List 16
Current time and date of the EGX200
© 2001 Schneider Electric All Rights Reserved
63230-314-200/A2
8/2001
Default
10
5
English
