CHAPTER 3—GETTING STARTED

CHAPTER CONTENTS

CHAPTER CONTENTS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

INTRODUCTION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

EGX200 QUICK START CHECKLIST . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

EGX200 INITIAL SETUP . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Setup Using a Web Browser . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Setup Using HyperTerminal. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Accessing the EGX200 Setup Utility. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
INTRODUCTION
This chapter contains a quick reference that lists the steps necessary to install and
operate the EGX200, as well as the initial instructions for setting up the EGX200 before
installation.
EGX200 QUICK START CHECKLIST
Use the steps in Table 3–1 as a quick start checklist for the EGX200. For complete
instructions, refer to the chapter listed:
Table 3–1: Quick Start Checklist
1. Wire the control power.
2. Set up the EGX200 for Ethernet communication via
HyperTerminal or web browser.
3. Install the EGX200.
4. Wire your RS-485 devices to the serial ports.
5. Launch your browser to configure the serial
communication parameters.
© 2001 Schneider Electric All Rights Reserved
Steps
Chapter 3—Getting Started
Reference
Chapter 4—Installation and Wiring
Chapter 3—Getting Started
Chapter 4—Installation and Wiring
Chapter 4—Installation and Wiring
Chapter 5—Operation
Chapter Contents
7
