63230-314-200/A2
8/2001

CHAPTER 5-OPERATION

CHAPTER CONTENTS

CHAPTER CONTENTS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
ACCESSING THE EGX200 OVER A NETWORK . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
Logging into the EGX200. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
EGX200 EMBEDDED WEB PAGE OPTIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
Communications Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
Ethernet Port Setup via LAN . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
Serial COM Port Setup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
Device List . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
Diagnostics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
Password Administration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
Administrator Account . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
User Account . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
Advanced Setup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38
Logging Out . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38

ACCESSING THE EGX200 OVER A NETWORK

This section tells how to access the EGX200 over a network or the Internet. After you
set up Ethernet parameters using HyperTerminal or a web browser, the EGX200 is
accessible via an Ethernet LAN and a web browser such as Internet Explorer. The
following section describes this process.

Logging into the EGX200

To log into the EGX200, follow these steps:
1. Launch your web browser (Microsoft's Internet Explorer v. 5.0 or higher).
2. In the address field (see Figure 5-1), type the IP address of the EGX200 (for
example, 150.200.250.50), and press Enter.
Figure 5-1: IP address entered in browser address field
