Appendix D-Specifications - PowerLogic EGX200 Instruction Bulletin

63230-314-200/A2
8/2001
APPENDIX D—SPECIFICATIONS
Table D–1: Specifications
CONTROL POWER INPUT SPECIFICATIONS
Operating Input Range
Burden, maximum
Isolation
ENVIRONMENTAL SPECIFICATIONS
Ambient Operating Temperature
Storage Temperature
Humidity Rating
Pollution Degree
PHYSICAL SPECIFICATIONS
Weight
Dimensions
REGULATORY/STANDARDS COMPLIANCE
Electromagnetic Interference
Radiated Emissions
Conducted Emissions
Immunity for Industrial Environments
Electrostatic Discharge (Air Discharge)
Immunity to Surge (Impulse Wave)
Immunity to Electrical Fast Transients
Power Frequency Magnetic Field
Voltage Dips
Voltage Interruptions
Conducted Immunity
Radiated Immunity
Safety
USA (Miscellaneous Apparatus)
Canada (Industrial Equipment)
Europe
© 2001 Schneider Electric All Rights Reserved
24 Vdc (±10%)
8 Watts
1.5 Kv
° °
–30 to +80 C.
° °
–40 to +85 C.
5–95% Relative Humidity (non-condensing) at +40°C
Class 2
1.5 lbs. (.68 Kg)
Length (7.88 in. / 200.2 mm), Width (4.81 in. / 122.2 mm),
Depth (1.07 in. / 27.2 mm)
EN 55022 / FCC Class A
EN 55022 / FCC Class A
EN 61000-6-2
EN 61000-4-2
EN 61000-4-5
EN 61000-4-4
EN 61000-4-8
EN 61000-4-11
EN 61000-4-11
EN 61000-4-6
EN 61000-4-3
UL 508
cUL (complies with CSA C22.2, #14–M91)
CE
Appendix D—Specifications
45
