Polycom VVX Business Media Phones User Guide
Note: VVX Expansion Modules not supported in UC Software 5.0.x
The VVX Expansion Modules are not supported on VVX phones running UC Software 5.0.x. The
expansion modules are supported only on VVX phones running UC Software 4.1.6, 4.1.7, and 5.1.x
and later.
The following features are available on the VVX Color Expansion Modules and VVX Expansion Modules
with a paper display:
● VVX Color Expansion Modules VVX Color Expansion Modules feature an easy-to-navigate
480x272 LCD display. Each color expansion module provides you with 28 line keys and three display
pages, supporting a total of 84 lines that
contacts, or Microsoft Lync presence contacts. You can connect up to three color expansion modules
to your phone to support an additional 252 line keys per phone.
● VVX Expansion Modules VVX Expansion Modules provide you with 40 line keys that
up as registrations, favorites, or busy lamp field contacts. You can connect up to three expansion
modules to your phone to support an additional 120 line keys per phone.

View VVX Expansion Module Hardware Features

The following figure illustrates the features, components, and keys available on the VVX Color Expansion
Modules. The table lists each numbered feature shown in this figure.
VVX Color Expansion Module features
Polycom, Inc.
you can set up as registrations, favorites, busy lamp field
you can set
