4. Operation Method (Basic Operation)

4.7 Operating with Operation Panel

When the inverter is operated with operation panel, as shown in "4.5 Setting
Frequency with Operation Panel" and "4.6 Setting Forward/Reverse Run with
Operation Panel", there are 4 combined modes by using parameters "P003: Run
Command Select" and "P004: Frequency Setting Signal".
This section will describe the four operation modes through specific examples.
Parameter P003:
"Run Command
Select"
■
Operation status when the panel is removed during operation
Sometimes OP trip will not occur if the operation panel is removed during
operation.
Item
Setting values of
"P003: Run
Command Select"
and "P004: Frequency
Setting Signal"
Inverter operation
status when the panel
is removed during
operation
Setting value "0"
Setting value "1"
Conditions of OP
trip occurrence
P003 = 0 or 1
or
P004 = 0
Operation stops
due to OP trip
occurrence.
Parameter P004: "Frequency Setting Signal"
Setting value "0"
Operation mode 1
Operation mode 2
Conditions of OP trip
non-occurrence
P003 is set to a
value greater than "2"
P004 is set to a value
greater than "1".
Operation continues.
Setting value "1"
Operation mode 3
Operation mode 4
and
