Panasonic VF0 Series 400V class Instruction Manual

400v class compact inverter
Hide thumbs
Table of Contents

Advertisement

Quick Links

Compact Inverter
VF0 Series 400V class

Instruction Manual

Read this manual carefully before
attempting to operate the inverter
and store it for future reference.
Panasonic Electric Works Co., Ltd
.

Advertisement

Table of Contents
loading

Related Manuals for Panasonic VF0 Series 400V class

Summary of Contents for Panasonic VF0 Series 400V class

  • Page 1: Instruction Manual

    Compact Inverter VF0 Series 400V class Instruction Manual Read this manual carefully before attempting to operate the inverter and store it for future reference. Panasonic Electric Works Co., Ltd...
  • Page 2 Important User Information The variety of uses for this equipment and difference between this solid state equipment and electromechanical equipment, means that the user of and those responsible for the applying of this equipment must ensure that the application and use of this product is acceptable and safe. Under no circumstances will Matsusita Electric Works, Ltd.
  • Page 3 1. PREFACE Important information relative to this manual # Manufactures and their respective engineering departments responsible for design and specification of electrical control equipment must refer to applicable industry standards and codes for specific safety guidelines and interface requirements. # The installer/user of this product is responsible to assume compliance with appropriate machine and operator safety codes or regulations within the factory environment which are beyond the scope and purpose of this documents.

  • Page 4: Safety Precautions

    Safety Precautions Read this manual and related documents before attempting to install, operate, service or inspect this inverter. Make sure that you have an understanding of the device, the safety information and all precautions before starting use. 1. INSTALLATION ATTENTION •...
  • Page 5 2. WIRING ATTENTION Always confirm that the input power is OFF before starting wiring. Failure to do so could lead to electric shocks or fires. Always connect the earth. Failure to do so could lead to electric shocks or fires. Wiring work must be carried out by a qualified technician.
  • Page 6 3. OPERATION ATTENTION Always close the terminal cover before turning the input power ON. Do not open the terminal cover while the power is ON. Doing so could lead to electric shock. Do not operate the switches with wet hands. Doing so could lead to electric shock.
  • Page 7 ATTENTION The heat sink fins and brake resistor (dedicated option) can reach high temperatures, so allow to cool before touching. Doing so could lead to burns. The inverter can be easily set to run from low speeds to high speeds. Confirm the tolerable range of the motor and machine before starting operation.

  • Page 8: General Precautions

    5. OTHERS ATTENTION Never modify the unit. Doing so could lead to electric shock or injury. General Precautions All diagrams in this instruction manual show the state with the cover or safety partitions removed to explain the details. Before operating the product, replace the covers and partitions to the positions specified, and operate the unit according to the instruction manual.

  • Page 9: Table Of Contents

    Contents Points for Handing ..............Special Precautions ............... Installation ................Outline Dimensions ..............Parts Identification ..............Main Circuit Wiring ..............Control Circuit Wiring ............. Basic Operation ..............Function of each mode ............Setting and Changing Functions ..........Functional Descriptions (Parameter Table) ......Functional Descriptions (By Parameter ) .......

  • Page 10: Points For Handing

    Points for Handling Follow this manual and precautions when handling this unit. Incorrect handling could lead to inhibited operation or a drop operating life. In the worst case, the inverter could be damaged. Use within +10%, −15% of the tolerable input Power supply voltage range, and within ±5% of the tolerable input frequency range.

  • Page 11: Special Precautions

    Special Precautions ♦ ♦ ♦ ♦ Use your inverter only within tolerable ambient temperature range. (–10°C to 50°C) Because the life of the inverter is greatly affected by ambient temperature, do not use it outside the specifications. Also, pay attention to the installation direction's and conditions.
  • Page 12 ♦ ♦ ♦ ♦ If a magnetic contactor is connected to the power supply side or the load side of the inverter, never use it to start or stop the motor (inverter). Switching the inverter on the power supply side ON and OFF frequently by a magnetic contactor, can cause the inverter to malfunction.

  • Page 13: Installation

    Installation ATTENTION Install the unit on a non-combustible material such as metal. Installing it on other material could lead to fire. Do not place the unit near flammable materials. Failure to do so could lead to fire. Do not hold the terminal cover during transportation. Failure to do so could cause the unit to drop and lead to injuries.

  • Page 14: Outline Dimensions

    Outline Dimensions 4-ø5 (Mounting holes) Unit: mm Note) The 1.5, 2.2 and 3.7kW capacities have a cooling fan at the broken line section shown on the left. • 3-phase 400V input type Unit: mm Inverter capacity 0.75kW 1.5, 2.2kW 3.7kW...

  • Page 15: Parts Identification

    Parts Identification Mounting hole Frame Operation panel Warning label Ground terminal Rating Terminal cover nameplate ∗ ∗ ∗ ∗ Check the rating nameplate Control wire lead-in hole Terminal cover to confirm that the ordered product has been delivered. Heat sink fins Main circuit wire lead-in hole Cooling fan...
  • Page 16 Note) This explanatory drawing shows the Explanation of inside of terminal cover state with the terminal cover removed. During normal use, do not remove the terminal cover. Mounting holes Control circuit terminal (signal input/output: 1-11) Control circuit terminal Main circuit terminal (relay output: A, B, C) (Main circuit terminal block layout) R S T...
  • Page 17 Explanation of operation panel button ⋅ Main display Mode button MODE Run button STOP Stop button Set button Frequency button setting dial The output frequency, current, line speed, error details, data for function Main display setting and parameter numbers are displayed. Run button This switch is used to start the inverter.

  • Page 18: Main Circuit Wiring

    Main Circuit Wiring CAUTION Always confirm that the input power is OFF before starting wiring. Failure to do so could lead to electric shock or fire. Always connect the ground wire. Failure to do so could lead to electric shock or fire. Wiring work must be carried out by a qualified technician.
  • Page 19 Wiring Note: Ground marking <<VF0 400V class>> Main circuit and grounding Power supply terminal screw size: M4 Main circuit terminal – Circuit breaker Moter (MCCB) Break resistor (Option) Always connect protective devices such as fuse for overcurrent, short circuits and leakage protection to the input. <<Precautions for using regenerative brakes>>...
  • Page 20 Connected device, wire size and main circuit terminal tightening torque Circuit breaker Inverter capacity Tightening torque Wire size (MCCB) 0.75 kW 1.5 kW 1.2 N·m (12.2 kgf·cm) (14AWG) 2.2 kW 3.7 kW Note 1) If the breaker's overcurrent trip is a magnetic type, the device could overheat due to higher harmonics.

  • Page 21: Control Circuit Wiring

    Control Circuit Wiring Wiring ∗ Only basic insulation (Protection against Electric Shock Class I, Overvoltage category II, Pollution degree 2) is provided on the control circuit terminals. The supplementary insulation must be provided on the final product to comply with CE Marking requirements. 10 11 COM NC NO Relay output...
  • Page 22 ♦ By using terminals No. 8 and 9, the output frequency can be controlled with the PWM signal. · No. 8: Frequency setting signal changeover input terminal (SW2) (OFF: PWM signal, ON: controlled with signal set in parameter P09) · No. 9: PWM signal input terminal Note 1) When controlling the output frequency with the PWM signal, parameters P22, P23 and P24 must be set.

  • Page 23: Basic Operation

    Basic Operation CAUTION Always close the terminal cover before turning the input power ON. Do not open the terminal cover while the power is ON. Failure to do so could lead to electric shock. Do not operate the switches or dials with wet hands. Failure to do so could lead to electric shock.

  • Page 24: Setting The Frequency

    Setting the frequency and forward/reverse run operation with the operation panel There are two methods for setting the frequency and carrying out forward/ reverse run operation with the operation panel. · Frequency setting: "Potentiometer setting method", "Digital setting method" · Forward/reverse run operation: "Forward run/reverse run method", "Start/ stop, rotation direction mode setting method"...
  • Page 25 2. Forward/reverse run operation 1) Forward run/reverse run method (Parameter P08 set to "1") Press the button (forward run) or button (reverse run) on the panel to select the rotation direction. Operation will start when the RUN button is pressed, and will stop when the STOP button is pressed. ∗...
  • Page 26 Operating with the operation panel - 1 (Factory setting state) · Forward/reverse run operation: Start/stop, rotation direction mode setting (Parameter P08=0) · Frequency setting: Potentiometer setting (Parameter P09=0) Main display [Example for rotating in forward direction at operating frequency 25Hz] The main display lamp will turn ON.
  • Page 27 Operating with the operation panel - 2 · Forward/reverse run operation: Forward run/reverse run (Parameter P08=1) · Frequency setting: Potentiometer setting (Parameter P09=0) [Example for rotating in forward direction at operating frequency 25Hz] Main display Power ON The main display lamp will turn ...
  • Page 28 [Continued from previous page, Example to rotate in reverse at operating frequency 50Hz] Main display  Press the (down) button, and set the rotation direction to Reverse run setting reverse run. · Current state (0: Stop) · Set rotation direction (r: Reverse run) Press the RUN button.
  • Page 29 Operating with the operation panel - 3 · Forward/reverse run operation: Start/stop, rotation direction mode setting (Parameter P08=0) · Frequency setting: Digital setting (Parameter P09=1) [Example for rotating in forward direction at operating frequency 25Hz] Main display Power ON The main display lamp will turn ON. Press the MODE button.
  • Page 30 [Continued from previous page, Example to rotate in reverse at operating frequency 50Hz] Main display MODE Press the MODE button. MODE Changing Press the MODE button.  Press the SET button. (The main display will flicker) rotation direction  Press the (up) button.

  • Page 31: Function Of Each Mode

    Function of Each Mode The VF0 has the following four modes. (1) Output frequency, current display mode, (2) Frequency setting, monitor mode, (3) Rotation direction setting mode, (4) Function setting mode Normally, use in the output frequency, current display mode. This mode is entered when the power is turned ON.

  • Page 32: Setting And Changing Functions

    Setting and Changing Functions Various function data can be changed and set when the operation is stopped. Note that some functions can be changed during operation. (See page 32.) Setting functions when operation is stopped. [Setting example: Change the maximum frequency from 50Hz to 60Hz] (Changing the parameter P03 data from "50"...
  • Page 33 Setting functions during operation CAUTION The motor and motor load fluctuation could change significantly and the motor may suddenly start or stop when data is being changed during operation. (Before making changes, ensure personal safety at all times.) Failure to do so could lead to injury. [Parameters that can be changed during operation] Parameter P01, P02 : 1st acceleration/deceleration time...
  • Page 34 [Setting example: To change torque boost level from 5 (%) to 15 (%)] Operation state (for 50Hz operation) Press the MODE button three times, and enter the "function MODE setting mode". Press the (up) button four times, and change the parameter No.

  • Page 35: Functional Descriptions (Parameter Table)

    Functional Descriptions (Parameter Table) Factory Parameter name Setting range setting data P01 1ST ACCELERATION TIME (sec) 0•0.1 to 999 05.0 P02 1ST DECELERATION TIME (sec) 0•0.1 to 999 05.0 P03 FREQUENCY RANGE (V/F PATTERN) 50•60•FF P04 V/F CURVE 0•1 P05 TORQUE BOOST LEVEL 0 to 40 P06 OVERLOAD FUNCTION 0•1•2•3...
  • Page 36 Factory Parameter name Setting range setting data P33 PRESET FREQUENCY 3 (Hz) 0•0.5 to 250 30.0 P34 PRESET FREQUENCY 4 (Hz) 0•0.5 to 250 40.0 P35 PRESET FREQUENCY 5 (Hz) 0•0.5 to 250 15.0 P36 PRESET FREQUENCY 6 (Hz) 0•0.5 to 250 25.0 P37 PRESET FREQUENCY 7 (Hz)
  • Page 37 Factory Parameter name Setting range setting data PASSWORD 0•1 to 999 DATA SETTING CLEAR 0•1 FAULT DISPLAY 1 Latest FAULT DISPLAY 2 Previous Refer to Second FAULT DISPLAY 3 page 74. to latest Third FAULT DISPLAY 4 to latest Note 1) The asterisk ∗ indicates the inverter's rated current. Note 2) The star mark indicates parameters that can be changed during operation.

  • Page 38: Functional Descriptions (By Parameter )

    Functional Descriptions (By Parameter ) 1st ACCELERATION TIME (Parameter P01) Used to set the time to accelerate to the maximum output Max. output frequency from 0.5Hz. frequency Data setting range (sec) 0.04 • 0.1 to 999 Setting unit (sec) 0.1 (0.1 to 100) 1 (100 to 999) Accelera- The display code for 0.04 sec.
  • Page 39 Note 1) Both the maximum output frequency and base frequency are set to 50Hz as the factory setting data. Note 2) Take note of the upper frequency clamp (parameter P54) when changing the maximum output frequency setting. V/F CURVE (Parameter P04) Used to select either the constant or square torque mode.
  • Page 40 OVERLOAD FUNCTION and OVERLOAD CURRENT (Parameter P06 and P07) Used to set the operation level of the electronic thermal relay when the motor overload is detected and the inverter output is to be stopped. Set these parameters according to the rated current of applicable motor.
  • Page 41 LOCAL/EXTERNAL CONTROL (Parameter P08) Used to select whether to carry out start/stop and forward/reverse with the operation panel (local) or with signals input from external devices. Data Panel Local/ setting reset Operation method and control terminal connection diagram External value function Start: RUN Stop: STOP Forward/reverse: Set in dr mode...
  • Page 42 REVERSE LOCKOUT (Parameter P10) Used to prevent reverse rotation when the motor is to be used only in the forward rotation. Data setting Details value Reverse rotation enabled (both forward/reverse rotation enabled) Reverse rotation prohibited (only forward rotation enabled) Note) When the reverse rotation prohibit setting is made, reverse rotation will be impossible in both the local and external modes.
  • Page 43 [Ramp-to-stop] [Forward/reverse] ∗ The frequency for applying the Forward DC brake is set by parameter Stop P12 stop frequency. frequency 0.5Hz (P12) ∗ The DC brake time when Operation frequency switching between forward run and reverse run is fixed to 0.1 Reverse DC brake time DC brake time...
  • Page 44 DECELERATION FREQUENCY HOLD (Parameter P18) When the set deceleration time is too short for the inertial load, this parameter can be used to temporarily reduce the deceleration rate to prevent an overvoltage trip. Data setting value Function details Stall prevention function disabled Stall prevention function enabled Note 1) Always set the setting data to "0"...
  • Page 45 [Multi-speed SW function] The combination of the SW inputs for when the SW function is set to multi-speed function is shown below. Operating frequency (Terminal No. 7) (Terminal No. 8) (Terminal No. 9) Speed 1 Speed 2 Speed 3 Speed 4 Speed 5 Speed 6 Speed 7...
  • Page 46 [Coast-to-stop function] A signal input terminal is set to carry out coast-to-stop from an external location. • If the signal input is turned ON (closed) during operation, "0.0" will appear and the inverter output will immediately stop. • If the input signal is turned OFF (opened) and the run signal is ON, the inverter will immediately start operation.
  • Page 47 PWM CONTROL FUNCTION SELECT, PWM SIGNAL AVERAGING and PWM SIGNAL CYCLE (Parameters P22, 23, 24) With this VF0, the operating frequency can be controlled with the PWM signals output from the PLC, etc. (Note that the tolerable PWM signal cycle is between 0.9ms and 1100ms.) [Parameter P22: PWM control function select] Note) If the PWM control function is Data setting value...
  • Page 48 [Parameter P23: PWM signal averaging] Setting data range (times) 1 to 100 The inverter measures and calculates the ON time and OFF time per PWM cycle, and recognizes the results as the frequency command value. This parameter is used to stabilize the frequency command value recognized by the inverter. For example, if the setting data is set to "5", the inverter will average five successive frequency command values, and will recognize the results as the final frequency command value.
  • Page 49 OUTPUT TR FUNCTION SELECT (Parameter P25) Used to set the functions of the open collector output (control terminals No. 10 -11). Data setting Conditions for open collector output to turn ON Function value (Setting data "7" is the PWM signal output) Run signal ON when start input signal is ON or during inverter output ON when the output frequency is within the set frequency...
  • Page 50 DETECT FREQUENCIES [OUTPUT TR], [OUTPUT RY] (Parameter P27 and P28) Used to set the frequency to be detected when outputting the frequency detection signal with the open collector output or relay output. [Parameter P27 : Open collector output detection frequency setting] [Parameter P28 : Relay output detection frequency setting] Data setting range (Hz) 000 •...
  • Page 51 PRESET FREQUENCIES 2 to 8 (Parameter P32 to P38) Used to program the speeds 2 to 8, frequencies for multi-step speed operation. [Parameter P32 : Speed 2 frequency setting] [Parameter P33 : Speed 3 frequency setting] [Parameter P34 : Speed 4 frequency setting] [Parameter P35 : Speed 5 frequency setting] [Parameter P36 : Speed 6 frequency setting] [Parameter P37 : Speed 7 frequency setting]...
  • Page 52 2nd BASE FREQUENCY (Parameter P41) Used to set the 2nd base frequency selected with 2nd characteristics select switch. Max. output frequency (P15) Data setting range (Hz) 45.0 to 250 2nd base frequency Note) The maximum output frequency will be the value set in parameter P03 (frequency range) or parameter P15 (max.
  • Page 53 SKIP FREQUENCIES 1 to 3 (Parameter P43 to P45) and SKIP FREQUENCY BAND WIDTH (Parameter P46) If the load mechanism resonates at a specific inverter output frequency, a continuous operation in that frequency band can be avoided by setting the skip frequency and the skip frequency band.
  • Page 54 POWER LOSS START MODE (Parameter P48) CAUTION Depending on the start mode function setting, if the run signal is ON and the power is turned ON or the power is restored after a power failure, the unit may start (restart) suddenly. (Design the machine so that personal safety can be ensured even if the unit starts suddenly.) Failure to do so could lead to injury.
  • Page 55 [When power is turned ON with run [When run signal is turned ON after signal ON] power is turned ON] LU level Power supply LU level Power supply Run signal Run signal Operation when Operation when "0" is set "0" is set "OP"...
  • Page 56 RIDE-THROUGH RESTART (Parameter P49) CAUTION Depending on the ride-through restart function settings, the motor may restart suddenly after the power is restored. (Ensure personal safety before restarting.) Failure to do so could lead to injury. Used to select the restart mode after an instantaneous power failure occurs, according to the load conditions and system.
  • Page 57 WAIT TIME (Parameter P50) Used to set the wait time for the start mode, the ride-through restart and retry functions. Data setting range (sec) 0.1 to 100 RETRY FUNCTION SELECT, NO. OF RETRIES (Parameters P51 and P52) CAUTION When the retry function is used, the unit may automatically start (restart) suddenly so do not approach the unit.
  • Page 58 LOWER and UPPER FREQUENCY CLAMP (Parameter P53 and P54) Used to set the lower and upper limits of the output frequency. [Parameter P53 : Lower frequency clamp setting] [Parameter P54 : Upper frequency clamp setting] Data setting range (Hz) 0.5 to 250 Setting unit (Hz) 0.1 (0.5 to 100Hz), 1 (100 to 250Hz) Note 1) If the upper frequency clamp is lower...
  • Page 59 BIAS/GAIN FUNCTION SELECT, BIAS FREQUENCY, GAIN FREQUENCY (Parameter P55, P56 and P57) The relation with the output frequency and frequency setting signal (panel potentiometer, external potentiometer, 0 to 5V, 0 to 10V, 4 to 20mA), can be changed randomly. Use this function according to the application.
  • Page 60 ANALOG/PWM OUTPUT FUNCTION SELECT (Parameter P58) The "0 to 5V voltage signal" output from the control circuit terminal No. 4 and the functions of the "output status signal (PWM)" output from terminals No. 10-11 can be set. Data setting value Details of function Signal proportional to output frequency is output Signal proportional to output current is output...
  • Page 61 MONITOR SELECT and LINE SPEED MULTIPLIER (Parameter P60 and P61) Used to select the details of the operation panel's main display. [Parameter P60: Monitor details selection] Data setting value Details displayed on operation panel Output frequency Line speed [Parameter P61: Line speed multiplier setting] Used to set the multiplier with respect to the frequency when the line speed is displayed on the operation panel's main display.
  • Page 62 OCS LEVEL (Parameter P63) The OCS level (overcurrent stall prevention operation level) and current clamp function level can be set with a percent (%) to the inverter's rated current. Data setting range (%) 1 to 200 (can be set in 1 units) Note 1) The OCS level and current clamp levels are the same.
  • Page 63 PASSWORD (Parameter P65) A password can be set to prevent unintentional changes to the parameter data after it has been set. 000 • 1 to 999 Data setting range ("000" indicates that there is no password.) [Procedures for changing parameter data after setting password] ∗...
  • Page 64 SETTING DATA CLEAR (Parameter P66) The set data can be changed to the factory setting data in a batch. Data setting range Details Data value that indicates normal state. Changes all data to the factory settings. Note) When "1" is displayed and the SET button is pressed, the display will automatically change to "0"...

  • Page 65: To Effectively Use The Inverter (Contents)

    To Effectively Use the Inverter Contents <<Page>> Changing from Local Control to External Control....Changing and Setting the Maximum Output Frequency ..Boosting Torque at Low Speeds ........Supplementary Explanation for Multi-function Terminal Input ................... 0V Stop Function ............... Resetting Fault Trips ............

  • Page 66: Changing From Local Control To External Control

    Changing from Local Control to External Control To enable external control by an external switch or PLC, follow the procedure below. (1) Enabling external control for start/stop and forward/reverse .......(Parameter P08) (To change parameter P08 from "0" to "2") [Changing procedure] [Terminal connection (P08=2)] Main display Common termional...

  • Page 67: Changing And Setting The Maximum Output Frequency

    Changing and Setting the Maximum Output Frequency The factory setting for the maximum output frequency is 50Hz. When changing the maximum output frequency, set the frequency range (V/F pattern) (parameter P03) to FF, and then change the max. output frequency setting (parameter P15).

  • Page 68: Boosting Torque At Low Speeds

    Boosting Torque at Low Speeds If a large torque is required at low speeds, increase the torque boost level (parameter P05) setting data value to increase the output voltage and thereby increase the torque. Note 1) If the boost level is too high, an overcurrent fault, overload fault or motor overheating could occur or the noise could increase.

  • Page 69: Supplementary Explanation For Multi-Function Terminal Input

    Supplementary Explanation for Multi-function Terminal Input Nine types of functions can be selected for the multi-function input terminals No. 7, 8, 9 (SW1, SW2, SW3). Refer to the following explanation and use these functions effectively. 1. Multi-speed SW function (Parameters: P19, P20, P21/Data setting value: 0) Eight types of frequencies can be selected, changed and controlled with the three switch signals SW1, 2 and 3.
  • Page 70 3. Reset lockout function (Parameters: P19, P20, P21/Data setting value: 2) This function holds the inverter's fault trip state. When this signal is input (ON), the fault cannot be reset with means other than turning the power OFF. This is effective for checking the details of the fault.
  • Page 71 5. Auxiliary stop function (Parameters: P19, P20, P21/Data setting value: 4) This function is used to carry out fault stop (emergency stop) from a source outside of the inverter. In the normal state, the ON signal is input. A fault stop will occur when this is turned OFF.
  • Page 72 7. Frequency signal changeover input function (Parameters: P19, P20, P21/Data setting value: 6) The frequency setting signal can be changed between the "external potentiometer" and "parameter P09 selection signal". <<Example>> When SW1 (parameter P19=6) is set to frequency changeover External potentiometer External potentiometer Note) Always connect the resistor R (200Ω)
  • Page 73 9. Frequency • (up) · • (down) setting function (Parameter: P21/Data setting value: 8) When the frequency setting is "digital setting with operation panel (parameter P09=1)", the frequency can be changed and saved with the external switch signals. ∗ When parameter P21 is set to "8", SW1, 2 and 3 will forcibly change to the following functions.

  • Page 74: 0V Stop Function

    0V Stop Function If the frequency setting signal is a command (panel potentiometer, external potentiometer, 0 to 5V, 0 to 10V, 4 to 20mA) other than the "digital setting with operation panel (parameter P09 = 1)", the inverter will start and stop at a boundary of approx.

  • Page 75: Individual Details And Remedies For Fault Trips

    Individual Details and Remedies for Fault Trips Fault trip memory ... The cause of the trip is saved in parameters P67 to P70. The details on the latest trip and the three prior trips is saved even if the power is turned OFF. (The details of the shipment inspection are saved when the unit is shipped.) Display Details and cause of faults...
  • Page 76 Display Details and cause of faults Remedies • An auxiliary stop signal was • Check the sequence circuit to input from control circuit confirm that the auxiliary stop terminal signal is correct. • The power was turned ON while • Check the power loss start mode the run signal was ON (parameter P48)

  • Page 77: Troubleshooting (1)

    Troubleshooting (1) CAUTION Wait at least 5 minutes after turning the input power OFF before starting inspection. Failure to do so could lead to electric shock. Maintenance, inspection and part replacement must be done by qualified persons. (Remove all metal personal belongings (watches, bracelets, etc.) before starting work.) (Use tools treated with insulation.) Failure to do so could lead to electric shock or injury.
  • Page 78 2. The motor does not rotate (when fault display is lit) When one of the faults on pages 74 and 75 is displayed and the motor has not rotated, check the following: (1) Is this the first time (or immediately after installation) power has been applied to the inverter? Check whether it has been in use.

  • Page 79: Troubleshooting (2)

    Troubleshooting (2) 1. MCCB trips. Is MCCB of suitable rating? Is input/output terminal wiring correct? Does a ground fault exist in main circuit wiring? MCCB failure or inverter malfunction (Contact Matsushita). Motor has over temperature Is the motor overloaded? • Reduce the load factor. •...

  • Page 80: Maintenance And Inspection

    Maintenance and Inspection CAUTION Wait at least 5 minutes after turning the input power OFF before starting inspection. Failure to do so could lead to electric shock. Maintenance, inspection and part replacement must be done by qualified persons. (Remove all metal personal belongings (watches, bracelets, etc.) before starting the work.) (Use tools treated with insulation.) Failure to do so could lead to electric shock or injury.

  • Page 81: Parts Replacement

    3. Parts replacement Wear fault (lifetime) … The lifetime is greatly dependent on the installation conditions. For example: 1) The lifetime of a relay depends on the wear condition of its contact surfaces. The contact current and load inductance are major factors. 2) The capacitor inside the inverter is used mainly as a smoothing filter and its lifetime varies greatly with temperature as internal chemical reactions take place.
  • Page 82 4. Maintenance and inspection table Note) Symbols in the check frequency field have the following meanings: means daily, means yearly and means every two years. Inspection Check Check item Check method Test criteria Instrument item frequency Ambient temp.: Ambient Installation See installation –10 to 50°C Thermometer...
  • Page 83 Check Inspection Check item Check method Test criteria Instrument item frequency (1) Check output line (1) Measure voltage (1) Line output voltage balance between output balance is 4V between phases terminals. max. during inverter operation without application. Operation Rectifier type (2) Check the (2) Simulate a checks...

  • Page 84: Specifications

    Specifications Rated specifications Three-phase 400V type Applied Rated output Rated output Power supply Product No. Mass motor output current capacity capacity BFV00074 0.75 kW 2.1 A 1.7 kVA 2.6 kVA 1.4 kg BFV00154 1.5 kW 3.8 A 3.0 kVA 3.6 kVA 1.4 kg BFV00224 2.2 kW...

  • Page 85: Common Specifications

    Common specifications Protection against Class I Electric Shock Overvoltage category Pollution degree Output frequency 0.5 to 250Hz range Frequency display Digital display Frequency ±0.5% of selected maximum set frequency (25±10°C) for analog setting accuracy Frequency setting Digital setting : 0.1Hz (1Hz over 100Hz) resolution Analog setting : 0.1Hz (50/60Hz mode) High carrier frequency sinusoidal PWM control...
  • Page 86 2nd voltage/ frequency Optional base frequency setting for 45 to 250Hz characteristics Torque boost Optional setting for 0 to 40% 2nd torque boost Optional setting for 0 to 40% level Accel./Decel. time 0.04 to 999 sec. (individual accel. and decel. time setting) Accel./Decel.
  • Page 87 Output specifications : 1c contact (contact capacity 250VAC, 0.5A resistance load) Relay output Output functions : Run signal, arrival signal, overload prealarm, frequency detection, reverse run signal, fault warning, Output frequency or line speed (selection changeover), output current, Operating condition rotation direction Symbol indicated when protective function activates (last 4 faults are Fault details...
