Appendix Function Parameter List
·If data is changed, the setting values of parameter "P160: The 2
Compensation Constant" and "P161: The 2
will be automatically changed to motor constants recommended by our
company.
nd
P160 The 2
·During vector control or when auto torque boost is performed through V/F
control, necessary voltage compensation constants should be set.
·Related setting values are the same as the those of 1
parameter "P133: Voltage Compenstion Constant".
nd
"P160: The 2 Voltage Compensation Constant" can be tuned automatically
with "P132: Motor Constant Measuring Function".
nd
P161 The 2
·During vector control or when auto torque boost is performed through V/F
control, necessary voltage compensation constants should be set.
·Related setting values are the same as the those of 1
parameter "P134: Slip Compenstion Frequency".
nd
"P161: The 2 Slip Compensation Frequency" can also be tuned
automatically by "P132: Motor Constant Measurement Function".
P162

Speed Search Select during Startup

Whether speed search is performed or not during startup can be set with this
parameter.
268
Voltage Compensation Constant
Slip Compensation Frequency
nd
Slip Compensation Frequency"
st
motor. Please refer to
st
motor. Please refer to
nd
Voltage
