ULI Specifications

Note: All circuits are power limited.
Overall
• 0 to 49 degrees Celsius, 0 to 95% RH (non-condensing) operating range
• Power input:
• Power supply ratings:
Model QIF-5000B Interface Module
• 2 Class B indicating circuits, one silenceable, one non-silenceable circuit connect to a fire alarm control panel
• 1 trouble contact output to a fire alarm control panel
• 1 GA contact input from a fire alarm control panel to allow two-stage operation
• 1 Bell cut drive for an external bell cut relay to a fire alarm control panel
• Fully supervised interface to QMP-5100B Master Paging Module
• Microcontroller based with full Watchdog Timer operation
• One minute paging inhibit after the first alarm
• Supervised pre-amplifier & tone generators
• Lamp test
• 18-1/2" high, 5-1/4" deep
• Current Consumption:
Model QPS-5000 & QBC-5000B Power Supply & Charger
• Primary input 120 VAC +10%, -15%, 60Hz, 12Amp
• Charging for up to 65 AH of 24 VDC batteries
• Float Type Charger
Model QMB-5000B Motherboard and Card Cage
• Accommodates one QIF-5000B, and up to seven amplifiers (360 Watts MAX speaker load). Connections for
QPS-5000, QBC-5000B, Batteries, and expansion connection to another QMB-5000B.
Model QAA-5160-70/25 Amplifier with one 70V or 25V, 60 Watt Zone
• 70.7Vrms or 25V constant voltage output
• One fully supervised Class "A" or "B" speaker Zone
• 60 watts per zone
• Freq. Response:
• Harmonic distortion less than 2.5% at 1 KHz
• Current consumption:
120 VAC, 60Hz, 12A (primary)
30A, 40V (secondary)
standby: 200mA
alarm: 200mA
ULI bandwidth from 800 to 2800 Hz
standby: 55mA
alarm: 350mA, plus 65mA/Watt Speaker Power
