QX-5000 Operating Instructions

QX-5000 Operating Instructions
Model: QX-5000, Emergency Zone Audio and Fire Fighter's Telephone System
Installation Manual: QX-5000 Series Emergency Zoned Audio Paging and Firefighters' Telephone System Installation and
Operation Manual, LT-616
The QX-5000 Emergency Zone Audio Paging and Firefighter's Telephone System is used in conjunction with a fire alarm control
panel such as the Mircom FA-1000 and FX-2000 series. As such, some of the operations described below refer to fire alarm
operations.
Normal
All indicators are off except for the A.C. ON LED.
Alarm / Evac
When the fire alarm control panel transmits an alarm to the QIF-5000B, the amplifiers' EVAC LEDs will illuminate and the EVAC tone
will be sent to the speakers. For the first minute after the first alarm, the QMP-5100B PAGE INHIBIT LED will also light.
Silenced Alarms
If the signals are silenced at the fire alarm control panel, the amplifiers' EVAC LEDs will extinguish and the EVAC tone will cease
being sent to the speakers. After a subsequent alarm, they will re-illuminate and the EVAC tone will re-sound.
Paging
If the microphone push-to-talk button is pressed while the PAGE INHIBIT LED is active, nothing will happen. If pressed (in
conjunction with the ALL-CALL, ALL-CALL MINUS or ZONE PAGE/EVAC buttons) when there is no alarm in the system or after an
alarm has been silenced, the microphone will page to the selected speakers. If pressed with an alarm in the system, the EVAC tone
will be suppressed during paging. If pressed during an alarm with an FA-1000 or FX-2000 Fire Alarm Control Panel, where bells are
used, the bells will be turned off during paging.
Mic / Amplifier / Amplifier / Zone Trouble
These troubles may cause paging to fail in one or all speaker zones.
Signal Gen / Amplifier / Zone Trouble
These troubles may cause EVAC tones to fail in one or all speaker zones.
Lamp Test
Pressing the Lamp Test button will turn on all indicators (LEDs).

System Service Notes

System Configuration
Electrical ratings:120VAC, 60 Hz, 12A
Number of QAA-5160-70 or QAA-5160-25 One Zone 60W Amplifiers____________
Number of QAA-5230-70/25 Two Zone 30W Amplifiers____________
Number of QAA-5230S-70/25 Dual Zone 30W Amplifiers Split ____________
Number of QAA-5230S-525-70/25 Dual Zone 30W Amplifiers Split ____________
Number of QAA-5415-70 or QAA-5415-25 Four Zone 15W Amplifiers____________
Class A or B Wiring
Battery Maintenance
The two 12 VDC sealed lead-acid batteries should be replaced after each period of 3 to 5 years of normal service. If the battery
Trouble indicator activates, obtain required service
25 Interchange Way, Vaughan, ON L4K 5W3
Tel: (905) 660-4655, Fax: (905) 660-4113
HIS SHEET SHOULD BE FRAMED AND PLACED NEAR THE PANEL
T
90
A B
.
Local Service Representative
Name: _________________________________________
Company: _________________________________________
Address: _________________________________________
Telephone: _________________________________________
Advanced Life Safety Solutions
