Appendix A: Specifications

ULI/ULC Integrated Fire Alarm and Audio Panel Specifications

Note: All circuits are power limited, unless specified otherwise.
Overall
PS-2040 Power Supply
• 0 to 49 degrees Celsius, 0 to 93 + or - 2% RH (non-condensing) operating range
• Power input:
• Power supply ratings:
Model QPS-5000N & QBC-5000N Power Supply & Charger
• Primary input 120 VAC, 60Hz, or 240 VAC, 50HZ, 12Amp, Not Power-limited
• Charging for up to 65 AH of 24 VDC batteries
• Float Type Charger
Model FNC-2000 Fire Network Controller Module
• Current consumption:
Model ANC-5000 Audio Network Controller Module
• Current consumption:
Model TNC-5000 Telephone Network Controller Module
• Current consumption:
Model FOM-2000-SP Fiber Optics Module
• Current consumption:
Model QAA-5160-70/25 Amplifier with one 70V or 25V, 60 Watt Zone
• 70.7Vrms or 25V constant voltage output
• One fully supervised Class "A" or "B" speaker Zone
• 60 watts per zone
• Freq. Response:
• Harmonic distortion less than 2.5% at 1 KHz
• Current consumption:
Model QAA-5230-70/25 Amplifier with two 70V or 25V, 30 Watt Zones
• 70.7Vrms or 25V constant voltage output
• Two fully supervised Class "A" or "B" speaker zones
• 30 watts per zone
• Freq. Response:
• Harmonic Distortion less than 2.5% at 1 KHz
• Current Consumption:
126
120 VAC, 60Hz, 12A or 240 VAC, 50Hz, 6A (primary), Not Power-limited
8.5A (x2), 18.85-0-18.85V (secondary)
13A, 29V (secondary)
standby: 190mA
190mA
alarm:
standby: 255mA
265mA
alarm:
195mA
standby:
215mA
alarm:
15mA
standby:
15mA
alarm:
ULI bandwidth from 800 to 2800 Hz
standby: 55mA
350mA, plus 65mA/Watt Speaker Power
alarm:
ULI bandwidth from 800 to 2800 Hz
standby: 55mA
350mA, plus 65mA/Watt Speaker Power
alarm:
