Paging Selector Switch and Backup Amplifier Configuration

Press the Lamp Test button once. The green AC On LED should go on steady.
Repeat the steps below until all amplifiers are assigned to all the paging selector switches 1 to 99.
Set the Config Switches #1 & #2 to the desired paging selector switch (Config Switch 2 is the 10's, Config Switch #1
is the 1's; these are read bottom to top), numbered between "01" to "99".
If an amplifier has been previously assigned to that paging selector switch, its green Page LED will be on. To
configure an amplifier (or a new amplifier) to that paging selector switch, press the Config - Advance button until the
selected amplifier's green Page LED turns on. Pressing the Config - Set button will assign that amplifier to that
paging selector switch. Any the previous amplifier assignment is deleted. The QIF-5000B green AC On LED will
flash briefly to confirm the new assignment.
Configure The backup amplifier by setting the Config switches 1 and 2 to "00" and press the Config - Set button to
confirm.

One Minute Inhibit Configuration

1. Press the Lamp Test button again, and the amber Lobby/Mic Trouble LED only should go on steady to select
whether or not the one minute inhibit (after the first fire alarm) on paging is enabled.
2. Set config switches 1 and 2 (config switch 2 is the 10's, config switch 1 is the 1's; these are read bottom to top)
to "00" to disable this feature, or "01" to enable this feature.
3. Press the Config - Set button to confirm. The green AC On LED will flash briefly to confirm this selection.

Tone Configuration

Note: For a QX-5000 used with a two-stage fire alarm control panel it is necessary to configure both the
alert and evacuation tones.
Alert Tone Setting
1. Press the Lamp Test button again, and the amber Sig Gen LED only should illuminate steadily to select the
desired alert tone.
2. Set the Config Switches #1 & #2 to the desired tone from the chart on the next page (Config Switch #2 is the
10's, Config Switch #1 is the 1's; these are read bottom to top).
3. Press the Config - Set button to confirm selection. The green AC On LED will flash briefly to confirm this
selection.
