Appendix A: Specifications

ULC Specifications

Note: All circuits are power limited.
Overall
• Zero to 49 degrees Celsius, 0 to 95% RH (non-condensing) operating range
• Power input:
• Power supply ratings:
• ULC requires use of Wuhan Sota Enertech Inc batteries
Model QIF-5000B Interface Module
• Two Class B Indicating circuits, one silenceable, one non-silenceable circuit connect to a fire alarm control
panel
• One trouble contact output to a fire alarm control panel
• One GA contact input from a fire alarm control panel to allow two-stage operation
• One bell cut drive for an external bell cut relay to a fire alarm control panel
• Fully supervised interface to QMP-5100B master paging module
• Microcontroller based with full Watchdog Timer operation
• One minute paging inhibit after the first alarm
• Supervised pre-amplifier & tone generators
• Lamp test
• 18-1/2" high, 5-1/4" deep
• Current consumption:
Model QPS-5000 & QBC-5000B Power Supply & Charger
• Primary input:
• Charging for up to 65 AH of 24 VDC batteries
• Float type charger
Model QMB-5000B Motherboard and Card Cage
• Accommodates one QIF-5000B, and up to 7 amplifiers (360 Watts MAX speaker load). Connections for QPS-
5000, QBC-5000B, batteries, and expansion connection to another QMB-5000B
Model QAA-5160-70/25 Amplifier with one 70V or 25V, 60 Watt Zone
• 70.7Vrms or 25V constant voltage output
• One fully supervised Class "A" or "B" speaker zone
• 60 watts per zone
• Freq. response +/-3dB from 400 to 4000Hz
• Harmonic distortion less than 2.5% at 1 KHz
• Current consumption:
120 VAC, 60Hz, 12A (primary)
30A, 40V (secondary)
standby: 200mA
alarm: 200mA
120 VAC, 60Hz, 12Amp
standby: 55mA
alarm: 350mA, plus 65mA/watt speaker power
