Displays & Controls

QIF-5000B Controls

Config - Set Button
Switches for configuring the system (for details see the Audio Cabinet Configuration section on page 30).
Config - Advance Button
Used during configuration (for details see the Audio Cabinet Configuration section on page 30).
Lamp Test Button
Momentarily activates all LED indicators in the audio cabinet.
Config - SW1
Switches used for configuring the system (for details see the Audio Cabinet Configuration section on page 30).
Config - SW2
Switches used for configuring the system (for details see the Audio Cabinet Configuration section on page 30).
QX-5000 System Reset
Performs a system reset on the QX-5000 (not the fire alarm).

Amplifier Displays

Page
The amplifier is connected to voice paging. Paging occurs on that particular amplifier zone.
Evac
The amplifier is connected to the evacuation tone.
Alert
The amplifier is connected to the alert tone.
Alert 2
The amplifier is connected to the alert tone 2.
Amp Trouble LED
Indicates an amplifier trouble by illuminating steady amber.
Zone Trouble LED
Indicates a zone field wiring trouble, by illuminating steady amber.
Notes:
• The QAA-5160-70/25 only has displays for "Amp-A", while the QAA-5230-70/25, QAA-5230-525-70 &
QAA-5230S-70/25 has displays for both "Amp-A" & "Amp-B".
• Trouble on the QX-5000 is annunciated on the fire alarm as trouble on its "trouble-only" circuit,
connected to the QX-5000 trouble contacts.
