Technical Details - Bellfires View Bell Medium 3 CF Installation Manual

APPLIANCE RATINGS
View Bell Medium 3 CF (Centre fi re)
Gas
Thermal effi ciency
Annual fi replace
effi ciency (P4)
Input maximum
Input minimum
Supply pressure
Manifold pressure
maximum (hot)
Manifold pressure
maximum (cold)
Manifold pressure
minimum
Main burner Injector marking
(back)
Main burner Injector marking
(front)
Pilot Injector marking
Bellfi res

TECHNICAL DETAILS

Natural gas
[%] 83.2
[%] 77.8
Btu/hr 40,000
Btu/hr 11,600
in. w.c.
kPa 1.74
in. w.c.
kPa 1.55
in. w.c.
kPa 1.50
in. w.c. 0.80
kPa 0.20
Nr. 190 (=1xØ1.90 mm)
Nr. 190 (=1xØ1.90 mm)
Nr. 36 (SIT 0.977.091)
71
7.0
6.2
6.0
Nr. 110 (=1xØ1.10 mm)
Nr. 125 (=1xØ1.25 mm)
Nr. 23 (SIT 0.977.150)
Installation instructions
Propane
84.2
79.0
32,000
8,900
11.0
2.74
10.8
2.69
10.8
2.69
0.80
0.20
