METAL-FAB - Sure-Seal Direct Vent Products 5" x 8" -
Available approved components:
METAL-FAB – Sure-Seal Direct Vent Products Concentric (= Co-axial) direct vent system
Size Diam. (in.) : 5" x 8"
Material Type : 0.012" 430 stainless steel inner wall
0.018" galvanized steel outer wall
Item no. Descrip! on
101 Bellfi res Adapter: 5⅛" x 7⅞" to 5" x 8" Metal-Fab
102 Horizontal Termina# on -Square Termina# on Cap
106 6" Pipe Straight Length assembly
108 12" Pipe Straight Length assembly
109 18" Pipe Straight Length assembly
110 24" Pipe Straight Length assembly
111 36" Pipe Straight Length assembly
112 48" Pipe Straight Length assembly
114 Adjustable Length 3"-10"
119 Elbow 45°
121 Elbow 90°
123 Wall support
126 Firestop
- Support Plate
- Decora# ve Cover Plate
128 Wall Thimble
132 Vinyl Siding Stand Off
140 Reducer: 5"x 8" to 4" x 6.5"
Bellfi res
VENT INSTALLATION
27
METAL-FAB Part no.
5DBA
5DHT
5D6
5D12
5D18
5D24
5D36
5D48
5DAL
5D45L
5D90L
5DWS
5DFS
5DSP
5DCP
5DWT
5DVS
54DTA
Installation instructions
