Mantle iron (option).
The optional mantle iron is intended for supporting the brickwork above the appliance.
The mantle iron must rest on the brickwork on both sides so that upward building is
possible. Level the mantle iron with the supplied bar set.
Keep a clearance of 0.1" (2 mm) between the mantle iron and the top of the side
panels.
The brickwork/plating must never rest directly on the appliance.
First remove the 2 mantle iron transport-spacers "REMOVE"
Note! Temporarily support the mantle iron, so that it does not fall forwards.
Bellfi res
BUILDING IN THE APPLIANCE
47
Bar set: • 2x draw bars
• 2x tension sleeves
• 2x M6 hooks
• 2x brass expansion
plugs M6
