Bellfires VIEW BELL TOPSHAM 3 CF Instructions For Use Manual

Gas fi re with closed combustion system
Hide thumbs Also See for VIEW BELL TOPSHAM 3 CF:

Advertisement

Quick Links

See also: Operating Manual , Installation Manual
INSTRUCTIONS FOR USE &
MANUAL DAILY MAINTENANCE
VIEW BELL TOPSHAM 3
CF / LF / PF
Gas fi re with closed combustion system
Bellfi res wishes you many cosy evenings with your new Bellfi res gas fi re
This document is an essential part of your gas fi re.
Read it carefully before use of the gas fi re and keep it in a safe place!
Serial number:
Production date:

Advertisement

loading

Related Manuals for Bellfires VIEW BELL TOPSHAM 3 CF

Summary of Contents for Bellfires VIEW BELL TOPSHAM 3 CF

  • Page 1 INSTRUCTIONS FOR USE & MANUAL DAILY MAINTENANCE VIEW BELL TOPSHAM 3 CF / LF / PF Gas fi re with closed combustion system Bellfi res wishes you many cosy evenings with your new Bellfi res gas fi re This document is an essential part of your gas fi re. Read it carefully before use of the gas fi...
  • Page 3 Bellfi res English BELLFIRES GAS FIRE WITH CLOSED COMBUSTION SYSTEM: View Bell Topsham 3 CF (Centre Fire) (VWBTS3 CF) View Bell Topsham 3 LF (Line Fire) (VWBTS3 LF) View Bell Topsham 3 PF (Premium Fire) (VWBTS3 PF) Instructions for use...
  • Page 4 Bellfi res English Instructions for use...

  • Page 5: Table Of Contents

    Bellfi res English CONTENTS Page 1. WARRANTY TERMS ................. 2. INSTRUCTIONS FOR USE ............... 3. USING THE APPLIANCE FOR THE FIRST TIME ........4. DAILY MAINTENANCE ................5. ANNUAL MAINTENANCE ................Instructions for use...
  • Page 6 Bellfi res English Instructions for use...

  • Page 7: Warranty Terms

    Bellfi res English WARRANTY TERMS Interfocos Warranty terms Interfocos B.V. guarantees the quality of the supplied Bellfi res hearth and the quality of the materials used. All Bellfi res hearths are developed and manufactured according to the highest possible quality standards. If, despite all this, something should prove amiss with the Bellfi...
  • Page 8 Bellfi res English it has not be used or maintained according to the instructions for use; it has been changed, neglected or roughly treated; it has been damaged as a result of external causes (outside the hearth itself), for example, lightning strike, water damage or fi re; 3.2.

  • Page 9: Instructions For Use

    Bellfi res English INSTRUCTIONS FOR USE INTRODUCTION Congratulations on your purchase of this modern Bellfi res gas fi re. This quality product will provide you with many years of enjoyment due to the fl ame effect and warmth that it provides.
  • Page 10 These burners each have their own specifi c fl ame effect, see below for an impression. View Bell Topsham 3 CF The appliance is supplied with a “Centre Fire” double burner: Both burners ON...
  • Page 11 Bellfi res English Only front burner ON View Bell Topsham 3 LF The appliance is supplied with a “Line Fire” double burner: Both burners ON Only front burner ON Instructions for use...
  • Page 12 Bellfi res English View Bell Topsham 3 PF The appliance is supplied with a “Premium Fire” double burner: Both burners ON Only front burner ON Natural gas: The above sketches provide an impression of the fl ame effect. This can differ from reality. The fl ame effect is namely dependant on the composition and supply pressure of the natural gas present.
  • Page 13 Bellfi res English OPERATION: REMOTE CONTROL 2.4.1 General Read these instructions carefully before lighting the fi re !! The appliance is operated by radio remote control. This comprises a hand-held transmitter and a receiver. The receiver is part of the gas control block assembly. The receiver and the gas control block are behind the (white) panel door (operating unit) next to the appliance.
  • Page 14 Bellfi res English The appliance is supplied with a “Premium Fire” (PF) double burner: Hand-held 1x 9V battery transmitter Receiver 6VDC Note: via the 5 wire cable No batteries in the receiver. from the Light-Module Light-Module 230 VAC Note: Hand-held transmitter and receiver are not interchangeable with previous models. The pilot light is situated in the front of the burner, behind a cowl.
  • Page 15 Bellfi res English °C/24 hour or °F/12 hour Temperature Clock setting Signal indication setting Battery status ON/OFF Temperature setting Time setting Light-symbol: Program Light / Dimmer Timer operation. Ambient setting lighting with “Premium Fire” (PF) Fan-symbol: has no double burner function for the appliance (Has no function with CF and LF...
  • Page 16 Bellfi res English Set the current time • The time display will fl ash after either: a installing the battery or b simultaneously pressing the (large fl ame) and (small fl ame). • While the screen is fl ashing, you can adjust the time. •...
  • Page 17 Bellfi res English Burner: The appliance’s entire burner consists of a “front burner” and a “rear burner”. Burner operation described below applies to: Both “front burner” and “rear burner”. (The AUX-symbol on the hand-held transmitter’s display is visible.) Only “front burner”. The “rear burner” is turned off. (The AUX-symbol on the hand-held transmitter’s display is not visible.) Possibilities of operation...
  • Page 18 Bellfi res English Manuel operation Here you can turn the burner on and off, and adjust the height of the fl ames. • Press (large fl ame) to turn on the burner and to increase the fl ame height. • Press (small fl...
  • Page 19 Bellfi res English • The lighting can be switched ON-OFF, and dimmed, if the main burner is burning, only the pilot light is burning, and when both burners are off. • 8 seconds after the light/dimmer have been set, the hand transmitter will automatically return to Operating night temperature thermostat (The appliance must be in the standby position and the...
  • Page 20 Bellfi res English Setting the desired temperature • Select the desired mode of operation by pressing the SET button briefl y. • Press the SET button until the temperature indication on the display begins to fl ash. • Set the temperature with (large fl...
  • Page 21 Bellfi res English 2.4.3 Operation (Remote control) Igniting the fi re • Open the gas supply valve in the gas pipe to the fi re. • Switch the hand-held transmitter to the position. • On the hand-held transmitter, press the OFF and (large fl...
  • Page 22 Bellfi res English • Possible error messages: * 3x short audio signal, audible when the motor-knob operates: Receiver batteries need changing soon (having heard this signal, the appliance can be ignited another ten times approximately). * 5 second unbroken tone: Error.
  • Page 23 Bellfi res English • Press button (large fl ame) to increase the fl ame level and to turn on the burner from the stand-by position. (Pressing briefl y the (large fl ame) button gradually increases the fl ames to the high position.) •...
  • Page 24 Bellfi res English Turning the “rear burner” on and off. Figure 5: Rear side of hand-held transmitter (battery cover) Instructions for turning the “rear burner” on and off After igniting the pilot light and burner the “front burner” and “rear burner” are both ON. The AUX-symbol on the hand-held transmitter’s display is visible.
  • Page 25 Bellfi res English Turning on the “rear burner”: • Simultaneously press the SET-button and (large fl ame) to turn the “rear burner” ON. The AUX-symbol on the hand-held transmitter’s display is visible. Notes: The “rear burner” always remains in the last switching position chosen, as long as the appliance is not completely turned off (burner and pilot light OFF).
  • Page 26 Bellfi res English Faults • If the signals from the hand-held transmitter do not seem to be reaching the receiver, the cause may be: * Spent batteries: replace the batteries. * An electronic problem: press the “RESET” button on the receiver. •...
  • Page 27 Bellfi res English The appliance is supplied with a “Premium Fire” (PF) double burner: • Receiver: Because the appliance is equipped with a 230 VAC connection, no batteries are present in the receiver. • Hand-held transmitter: The hand-held transmitter battery has a service life of approx. one year. We recommend you use alkaline batteries.

  • Page 28: Using The Appliance For The First Time

    Bellfi res English USING THE APPLIANCE FOR THE FIRST TIME The gas fi re is coated with a lacquer layer resistant to high temperature. During the fi rst hours of operation, the burning in of the lacquer may result in an unpleasant smell.

  • Page 29: Daily Maintenance

    Bellfi res English DAILY MAINTENANCE • Ensure that as little dust, and as few particles of cigarette smoke, candles and oil lamps as possible pollute the air in the room in which the appliance is used. Heating of these particles by the convection system of the appliance could lead to discoloration of the walls and ceiling.

  • Page 30: Annual Maintenance

    Bellfi res English ANNUAL MAINTENANCE It is essential that the appliance, the complete concentric fl ue system (where possible) and the outlet are cleaned and inspected annually by a recognised fi tter/gas specialist. The safe operation of the appliance will thus remain guaranteed.
  • Page 32 Your Bellfi res dealer 01 - 010515 - 340360...
