Bellfires Derby Installation Instructions And Instructions For Use

Gas fires with closed combustion system original bell-series - retro bell-series horizon bell medium / small-series - corner bell small l/r vertical bell-series - view bell-series

Hide thumbs Also See for Derby:

Installation instructions and instructions for use (99 pages)

Table Of Contents

See also: Instructions for Use, Installation and Maintenance

www.tapis.pl

INSTALLATION INSTRUCTIONS AND INSTRUCTIONS FOR USE

Gas ﬁ res with closed combustion system

Original Bell-series - Retro Bell-series

Horizon Bell Medium / Small-series - Corner Bell Small L/R

Vertical Bell-series - View Bell-series

Bellﬁ res wishes you many cosy evenings with your new Bellﬁ res gas ﬁ re

This document is an essential part of your gas ﬁ re.

Read it carefully before installation and use of the

gas ﬁ re and keep it in a safe place!

Table of Contents

Summary of Contents for Bellfires Derby

Page 1 www.tapis.pl INSTALLATION INSTRUCTIONS AND INSTRUCTIONS FOR USE Gas ﬁ res with closed combustion system Original Bell-series - Retro Bell-series Horizon Bell Medium / Small-series - Corner Bell Small L/R Vertical Bell-series - View Bell-series Bellﬁ res wishes you many cosy evenings with your new Bellﬁ res gas ﬁ re This document is an essential part of your gas ﬁ...
Page 3 Bellﬁ res English BELLFIRES GAS FIRES WITH CLOSED COMBUSTION SYSTEM: Original Bell - series: Derby (DY) Derby II (DY II) Jersey (JY) Flat Bell (FB) Topsham (TS) Topsham Tunnel (TST) York (YK) Kent (KT) Retro Bell - series: Retro Bell Intermediate...
Page 4 Bellﬁ res English Instructions for use and installation instructions...
Page 5: Table Of Contents
Bellﬁ res English CONTENTS Page 1. WARRANTY TERMS ................. 2. INSTRUCTIONS FOR USE ............... 3. INSTALLATION INSTRUCTIONS .............. 4. MAINTENANCE ..................5. FAULTS ...................... 6. ELECTRICAL DIAGRAM ................7. DIMENSIONS .................... 8. TECHNICAL DETAILS/REGULATIONS ............ 9. REPLACEMENT PARTS LIST ..............10.
Page 6 Bellﬁ res English Instructions for use and installation instructions...
Page 7: Warranty Terms
Bellﬁ res English WARRANTY TERMS Bellﬁ res gas ﬁ re Warranty Bellﬁ res guarantees the quality of the supplied hearth and the quality of the materials used. This warranty runs for a period of twelve (12) months from ﬁ rst use of the hearth and covers defects which are a result of construction faults or the failure of component parts.
Page 8 Bellﬁ res English Instructions for use and installation instructions...
Page 9: Instructions For Use
Bellﬁ res English INSTRUCTIONS FOR USE INTRODUCTION Congratulations on your purchase of this modern Bellﬁ res gas ﬁ re. This quality product will provide you with many years of enjoyment due to the ﬂ ame effect and warmth that it provides. Please read the instructions for use carefully before using the appliance for the ﬁ...
Page 10 Bellﬁ res English Ensure at all times that children and other people who are not aware of the operation of the gas appliance are only in the vicinity of the appliance exclusively under supervision. Use a ﬁ reguard to protect the people and children mentioned above against possible burns.
Page 11 Bellﬁ res English 2.4.1 Igniting the ﬁ re • Open the gas supply valve in the gas pipe to the appliance. • Press in the control knob and turn it (clockwise) as far as possible. It is now in the “off”...
Page 12 Bellﬁ res English REMOTE CONTROL REMOTE CONTROL 2.5.1 General The appliance is opperated by radio remote control. This comprises a hand-held transmitter and a receiver. The receiver is part of the gas control block assembly. The receiver and the gas control block are behind the (white) panel door (operating unit) next to the appliance.
Page 13 Bellﬁ res English Figure 2: Hand-held transmitter Set the display • Connect the batteries. By simultaneously pressing OFF and (small ﬂ ame), can be switched from °F (and 12 hour clock) to °C (and 24 hour clock), or vice versa. •...
Page 14 Bellﬁ res English Figure 3: Receiver “RESET” button Operating possibilities It is possible to use the remote control in 3 ways to operate the appliance: You can cycle through the menu with operating possibilities by repeatedly depressing the SET button. the selected starting time (P1 or P2 ) or stopping time (P1 or P2 ) is...
Page 15 Bellﬁ res English Manual operation Here you can turn the burner on and off, and adjust the height of the ﬂ ames. • Press (large ﬂ ame) to turn on the burner and to increase the ﬂ ame height. • Press (small ﬂ...
Page 16 Bellﬁ res English Setting the desired temperature by pressing the SET button • Select the desired mode of operation brieﬂ y. • Hold the SET button until the display ﬂ ashes. • Set the temperature with (large ﬂ ame) or (small ﬂ...
Page 17 Bellﬁ res English Connection Piezo Igniter (only for MANual control) ON/OFF Switch Operating Knob 8-wire Receiver Jack Motor-Knob Microswitch (in maximum position) Figure 4: Gas regulating block; Operating Knob in ON-position • Possible error messages: * 3x short audio signal, audible when the motor-knob operates: Receiver batteries need changing soon (having heard this signal, the appliance can be ignited another ten times approximately).
Page 18 Bellﬁ res English Important: • If you turn on the main burner by pressing the (large ﬂ ame) button, it must ignite within 10 seconds. If this does not happen, immediately close the gas tap and warn the ﬁ tter. •...
Page 19 Bellﬁ res English 2 Receiver: * Carefully pull the receiver assembly out of the compartment behind the (white) panel door. * Open the cover. * Remove the batteries from the battery compartment. * Place four new 1.5V batteries (LR6 or AA type) as indicated in the battery compartment.
Page 20 Bellﬁ res English Igniting the ﬁ re • Open the gas supply valve in the gas pipe to the ﬁ re. • Switch the “O I” switch on the gas regulating block to the “I” position. • Turn the motor-knob on the gas regulating block as far as it will go in a clockwise direction.
Page 21 Bellﬁ res English 2.6 USING THE APPLIANCE FOR THE FIRST TIME The gas ﬁ re is coated with a lacquer layer resistant to high temperature. During the ﬁ rst hours of operation, the burning in of the lacquer may result in an unpleasant smell.
Page 22: Installation Instructions
Bellﬁ res English INSTALLATION INSTRUCTIONS 3.1 GENERAL The gas ﬁ re must be positioned and connected as a “room sealed system” (balance ﬂ ue) appliance by a “Gas Safe Register” registered gas installation engineer in accordance with the following installation instructions, nationally and locally applicable regulations (see “Technical Details/ Regulations”...
Page 23 Bellﬁ res English 3.2 BARBAS AND ONTOP CONCENTRIC FLUE Ø100 MM - Ø150 MM SYSTEM The appliance is in combination with the concentric ﬂ ue system [Ø100 mm – Ø150 mm] (either rigid or ﬂ exible) of Barbas or Ontop (US system) compliant with the European CE norm for gas appliances, and may therefore only be used with these systems.
Page 24 Bellﬁ res English Wall-mounted outlet: >0.5 m Figure 7: Wall-mounted outlet This must be positioned at least 0.5 m from: • the corner of the building • the roof overhang, the rain gutter • balconies etc., unless the exhaust construction extends to at least the face of the protruding section.
Page 25 Bellﬁ res English 3.3.1.2. Positioning the outlet to avoid affecting the surrounding area All listed “distances” in this section are no more than guidelines. For the exact minimum “distances”, please consult your national and local directives. Distance” = minimum distance required for positioning of the outlet to avoid adverse effects with respect to: A.
Page 26 Bellﬁ res English Wall-mounted outlet: To avoid adverse effects Distance: outlet - A, B or C At walls in buildings with staggered Not permitted if A, B, or C are located heights. above the outlet. On a wall - general. (*) Above the outlet: >2 m Below the outlet:...
Page 27 Bellﬁ res English GENERAL SERVICES 3.4.1 The Fume Channel/Combustion Air Intake The combined fume channel and combustion air intake requires one of the following Barbas or Ontop concentric ﬂ ue system conﬁ gurations. Exception: the View Bell Vertical is only suitable for the Barbas mark. Important: Due to the high temperature of the outer walls (approx.
Page 28 All appliances, 0 - 0.6 m 0.5 - 1.0 m except... 0 - 3.0 m 1.0 - 3.0 m ... Derby 0 - 0.6 m 1.0 - 2.0 m Derby II Jersey 0 - 3.6 m 2.0 - 3.0 m Horizon Bell Medium ...
Page 29 Bellﬁ res English 10, 11, 12, 13 Item descriptions: see 3.4.2 Appliance: Distance Y Assemble (min.-max.) restriction plate All appliances, except... 2.0 - 12.0 m ... Jersey ... Vertical Bell Small 2.0 - 12.0 m Width: B = 30 mm ...
Page 30 Bellﬁ res English 14, 15 10, 11, 12, 13 Item descriptions: see 3.4.2 Appliance: Distance Y (*) Distance X (*) Distance Y Assemble (min.-max.) (min.-max.) (min.-max.) restriction plate All appliances, except... 1.0 - 11.0 m 0 - 3.0 m 1.0 - 11.0 m ...
Page 31 Bellﬁ res English FLEXIBLE CONCENTRIC FLUE Ø100 mm - Ø150 mm SYSTEM CONNECTION POSSIBILITIES 10, 11, 12, 13 Item descriptions: see 3.4.2 Appliance: Distance Y Assemble (min.-max.) restriction plate All appliances, except... 2.0 - 12.0 m ... Jersey ... Vertical Bell Small 2.0 - 12.0 m Width: B = 30 mm ...
Page 32 Bellﬁ res English > 45° 10, 11, 12, 13 Item descriptions: see 3.4.2 Appliance: Distance Y (*) Distance X (*) Distance Y Assemble (min.-max.) (min.-max.) (min.-max.) restriction plate All appliances, except... 1.0 - 11.0 m 0 - 3.0 m 1.0 - 11.0 m ...
Page 33 Bellﬁ res English Item descriptions: see 3.4.2 Appliance: Distance Y Assemble (min.-max.) restriction plate All appliances, except... 2.0 - 12.0 m ... Jersey ... Vertical Bell Small 2.0 - 12.0 m Width: B = 30 mm ... Vertical Bell Large Tunnel ...
Page 34 Bellﬁ res English > 45° Item descriptions: see 3.4.2 Appliance: Distance Y (*) Distance X (*) Distance Y Assemble (min.-max.) (min.-max.) (min.-max.) restriction plate All appliances, except... 1.0 - 11.0 m 0 - 3.0 m 1.0 - 11.0 m ... View Bell Vertical 1.0 - 11.0 m 0 - 3.0 m 1.0 - 11.0 m...
Page 35 Bellﬁ res English 3.4.2 Item descriptions for ﬁ gures 9 t/m 15. FIG. NO. DESCRIPTION Gas ﬁ re Restriction plate (if applicable) Chimney, min. Ø150 mm internal, totally gas tight Chimney or ﬁ reproof sleeving. Min. Ø160 mm internal Ø100 mm internal ﬂ exible stainless steel gas vent chimney liner AISI 316TI Ø150 mm internal ﬂ...
Page 36 Bellﬁ res English FIG. ART. / Color(*) Application ORDER DESCRIPTION antr. RIGID FLEX 302189 Ceiling plate for transition Ø100 mm / Ø150 mm rigid - Ø100 mm (ﬂ ex.). Stainless steel adapter piece (100) from ﬁ re to ﬂ exible, Ø100 302278 mm external (rigid) x Ø107 mm internal (ﬂ...
Page 37 Bellﬁ res English 3.4.3 Gas connection Operation (gas regulating block (and receiver)) within the appliance: The gas connection Ø12 mm (3/8”) is located on the right-hand side of the appliance. Operation (gas regulating block (and receiver)) outside the appliance (in the operating unit): The gas connection is situated where the operating unit is built in near to the appliance.
Page 38 Bellﬁ res English Never use combustible materials during the installation. Ventilate the ﬁ replace, by allowing vents above and below the ﬁ replace. During installation of the gas ﬁ re, a clearance of 3 mm should be maintained on all sides of the appliance to allow for expansion of the appliance during operation.
Page 39 Bellﬁ res English Figure 17: Use of convection package and ventilation of ﬁ replace When ﬁ tting the appliance, it can be levelled with the adjustable feet. Position the gas supply pipe such that it can be easily mounted after installation. If the appliance has a operating unit, the gas pipe must lead to where the operating unit (built in), the gas regulating block (and the receiver) assembly are ﬁ...
Page 40 Bellﬁ res English 3.5.1 Connecting the gas Important: During gas connection, take care not to twist the gas regulating block. Make sure that both the gas regulating block and the supply pipes are not subjected to stresses. Appliance with operation in the separate operating unit (built in or otherwise): •...
Page 41 Bellﬁ res English Remote control Gas regulating block and receiver in operating unit Gas regulating block Gas supply connection 3/8” - Ø12 / Ø15 mm insertion Burner piping connection Ø8 mm insertion Thermocouple connection M 10x1 mm insertion Pilot light piping connection Ø4 mm insertion Receiver Piezo cable connection Figure 19: Remote control: Gas regulating block and receiver in operating unit...
Page 42: Remote Control
Bellﬁ res English Remote control The photo below shows how the piping for a remote control gas regulating block must be ﬁ tted. Maximum Rate Pilot Gas Adjustment Adjustment Screw (with Screwdriver) Motor-knob Operating-Knob (Tab 2,8 x 0,8 mm) Connection piezo cable (Hand Control) Side-inlet Side-outlet...
Page 43 Bellﬁ res English Operating-Knob Motor-Knob (Remote control ↔ Hand control) Connection Microswitch Piezo Igniter (Hand control) Piezo Igniter (Hand control) “O I” Switch Connection 8-Wire Receiver Jack Pilot Gas Figure 21: Gas regulating block Hand control Gas regulating block in operating unit. The photo below shows how the piping for a hand control gas regulating block must be ﬁ...
Page 44 Bellﬁ res English Appliance with operation in the separate operating unit (built in or otherwise). • Gas control block and piping supplied as an pre-assembly. First detach the bracket with the gas control block from the appliance. Fit the separate control unit max. 50 cm from the appliance. Fit the receiver in the top of the control unit.
Page 45 Bellﬁ res English The optional mantle iron is intended for supporting the brickwork above the hearth. The mantle iron must rest on the brickwork on both sides so that upward building is possible. The brickwork therefore must not rest on the ﬁ replace; there must be approx. 3 mm clearance in connection with the weight.
Page 46 Bellﬁ res English 3.5.5.1 Ceramic log set + embers 1 Place the ceramic mat on the burner in such a way that the holes in the mat are in line with the burner openings. 2 Remove the embers (2x 100 gram) carefully from their packaging and spread them evenly over the burner mat and the grate around the burner.
Page 47 Retro Bell Intermediate, Flat Bell Embers must not be placed next to the pilot light burner Group C: Derby, Derby II, Horizon Bell Small Embers must not be placed next to the pilot light burner Instructions for use and installation instructions...
Page 48 Bellﬁ res English Group D: Topsham Tunnel Position the logs as shown below. The photos show the situation from either side. • Embers must not be placed next to the pilot light burner Group E: Horizon Bell Small Tunnel • Position the logs as shown below. Embers must not be placed next to the pilot light burner Instructions for use and installation instructions...
Page 49 Bellﬁ res English Group F (a): Jersey: Natural gas Embers must not be placed next to the pilot light burner Group F (b): Jersey: Propane Keep the burner oriﬁ ces unblocked Embers must not be placed next to the pilot light burner Instructions for use and installation instructions...
Page 50 Bellﬁ res English Group G (a): Vertical Bell Small: Natural gas Embers must not be placed next to the pilot light burner Instructions for use and installation instructions...
Page 51 Bellﬁ res English Group G (b): Vertical Bell Small: Propane Keep the burner oriﬁ ces unblocked Embers must not be placed next to the pilot light burner Instructions for use and installation instructions...
Page 52 Bellﬁ res English Group H: Vertical Bell Large Tunnel Embers must not be placed next to the pilot light burner Instructions for use and installation instructions...
Page 53 Bellﬁ res English Group I (a): Horizon Bell Medium: Natural gas Embers must not be placed next to the pilot light burner Instructions for use and installation instructions...
Page 54 Bellﬁ res English Group I (b): Horizon Bell Medium: Propane Embers must not be placed next to the pilot light burner Keep the burner oriﬁ ces unblocked Instructions for use and installation instructions...
Page 55 Bellﬁ res English Groep J (a): View Bell Vertical: Natural gas Embers must not be placed next to the pilot light burner Log no Log no Log no Log no Instructions for use and installation instructions...
Page 56 Bellﬁ res English Groep J (b): View Bell Vertical: Propane Keep the burner oriﬁ ces unblocked Log no Log no Log no Log no Instructions for use and installation instructions...
Page 57 Bellﬁ res English 3.5.5.2 Marble pebbles 1 Place the ceramic mat on the burner in such a way that the holes in the mat are in line with the burner openings. 2 Spread the pebbles over the whole burner bed (burner and grid around the burner). Make sure that the pilot light remains free.
Page 58 Bellﬁ res English Important: • Do not place any marble pebbles in front of the pilot light. Make sure that the pilot light can burn freely over the main burner. Keep the burner oriﬁ ces unblocked. • Only this way a proper ignition of the main burner is ensured. Once the logs/marble pebbles have been positioned, the door must be closed again or the glass must be replaced.
Page 59 Bellﬁ res English The following restriction plate is supplied: • Jersey • Vertical Bell Small Restriction plate : Width: B = 30 mm • Vertical Bell Large Tunnel : • Horizon Bell Medium • View Bell Vertical : Restriction plates : Width: B = 30 mm Width: B = 50 mm Width: B = 65 mm 3.5.7 Checking the appliance following installation...
Page 60: Maintenance
Bellﬁ res English MAINTENANCE 4.1 ANNUAL MAINTENANCE It is essential that the appliance, the complete concentric ﬂ ue system and the outlet are cleaned and inspected annually by a recognised ﬁ tter/gas specialist. The safe operation of the appliance will thus remain guaranteed. Maintenance consists of the following: •...
Page 61: Faults
Bellﬁ res English FAULTS Possible reasons for the gas ﬁ re going out are: • The concentric ﬂ ue system is not installed according to one of the methods detailed in Paragraph 3.4 • An incorrect “ﬂ ue gas restriction plate” is ﬁ tted. •...
Page 62: Electrical Diagram
Bellﬁ res English ELECTRICAL DIAGRAM 6.1 MODELS WITH REMOTE CONTROL Operating-Knob Motor- knob Gas regulating block “black” Thermo - “O I” Switch current “red” Interrupter Block 8 Wire connecting cable cable 2 cable 1 Thermo- Ignition cable Antenna couple “red” “yellow”...
Page 63: Dimensions
Available with control unit in appliance (bottom) or in separate operating unit, see page 72 (**) Control unit in separate operating unit, see page 72 (***) Control unit in appliance (bottom) 7.1 DERBY / DERBY II (**) 7.2 JERSEY (**) Instructions for use and installation instructions...
Page 64 Bellﬁ res English 7.3 FLAT BELL (*) 7.4 TOPSHAM (*) Instructions for use and installation instructions...
Page 65 Bellﬁ res English 7.5 TOPSHAM TUNNEL (*) 7.6 YORK (*) Instructions for use and installation instructions...
Page 66 Bellﬁ res English 7.7 KENT (*) 7.8 RETRO BELL INTERMEDIATE (***) Instructions for use and installation instructions...
Page 67 Bellﬁ res English 7.9 RETRO BELL SMALL (***) 7.10 VIEW BELL SMALL (**) Instructions for use and installation instructions...
Page 68 Bellﬁ res English 7.11 CORNER BELL SMALL (**) 7.12 HORIZON BELL MEDIUM (**) Instructions for use and installation instructions...
Page 69 Bellﬁ res English 7.13 HORIZON BELL SMALL (**) 7.14 HORIZON BELL SMALL TUNNEL (**) Instructions for use and installation instructions...
Page 70 Bellﬁ res English 7.15 VERTICAL BELL LARGE (**) 7.16 VERTICAL BELL LARGE TUNNEL (**) Instructions for use and installation instructions...
Page 71 Bellﬁ res English 7.17 VERTICAL BELL SMALL (**) 7.18 VIEW BELL VERTICAL (**) Instructions for use and installation instructions...
Page 72 Bellﬁ res English OPERATING UNIT Instructions for use and installation instructions...
Page 73: Technical Details/Regulations
National installation regulations: Gas safety installation and use regulations 1984 plus all relevant safety and building regulations concerning ﬁ re installation Model : DERBY Country : GB; Great Britain/IE; Ireland : GB; Great Britain/IE; Ireland Product identiﬁ cation no : 0063BL5625...
Page 74 Bellﬁ res English Model : DERBY II Country : GB; Great Britain/IE; Ireland : GB; Great Britain/IE; Ireland Product identiﬁ cation no : 0063BL5625 : 0063BL5625 Type of appliance under CE-norm Category of appliance Natural gas G20 Propane G31 Nominal heat input (Gross caloriﬁ c value) : 11.5 kW : 9.5 kW...
Page 75 Bellﬁ res English Model : JERSEY Country : GB; Great Britain/IE; Ireland : GB; Great Britain/IE; Ireland Product identiﬁ cation no : 0063BL5625 : 0063BL5625 Type of appliance under CE-norm Category of appliance Natural gas G20 Propane G31 Nominal heat input (Gross caloriﬁ c value) : 9.5 kW : 6.8 kW Nominal heat output : 6.8 kW...
Page 76 Bellﬁ res English Model : YORK TOPSHAM KENT VIEW BELL SMALL TOPSHAM TUNNEL SANDUR SANDUR PANORAMA Country : GB; Great Britain/IE; Ireland : GB; Great Britain/IE; Ireland Product identiﬁ cation no : 0063BL5625 : 0063BL5625 Type of appliance under CE-norm Category of appliance Natural gas G20 Propane G31...
Page 77 Bellﬁ res English Model : FLAT BELL RETRO BELL INTERMEDIATE Country : GB; Great Britain/IE; Ireland : GB; Great Britain/IE; Ireland Product identiﬁ cation no : 0063BL5625 : 0063BL5625 Type of appliance under CE-norm Category of appliance Natural gas G20 Propane G31 Nominal heat input (Gross caloriﬁ...
Page 78 Bellﬁ res English Model : RETRO BELL SMALL Country : GB; Great Britain/IE; Ireland : GB; Great Britain/IE; Ireland Product identiﬁ cation no : 0063BL5625 : 0063BL5625 Type of appliance under CE-norm Category of appliance Natural gas G20 Propane G31 Nominal heat input (Gross caloriﬁ...
Page 79 Bellﬁ res English Model : CORNER BELL SMALL Country : GB; Great Britain/IE; Ireland : GB; Great Britain/IE; Ireland Product identiﬁ cation no : 0063BL5625 : 0063BL5625 Type of appliance under CE-norm Category of appliance Natural gas G20 Propane G31 Nominal heat input (Gross caloriﬁ...
Page 80 Bellﬁ res English Model : HORIZON BELL MEDIUM Country : GB; Great Britain/IE; Ireland : GB; Great Britain/IE; Ireland Product identiﬁ cation no : 0063BL5625 : 0063BL5625 Type of appliance under CE-norm Category of appliance Natural gas G20 Butane/Propane G30/G31 Nominal heat input (Gross caloriﬁ...
Page 81 Bellﬁ res English Model : HORIZON BELL SMALL HORIZON BELL SMALL TUNNEL Country : GB; Great Britain/IE; Ireland : GB; Great Britain/IE; Ireland Product identiﬁ cation no : 0063BL5625 : 0063BL5625 Type of appliance under CE-norm Category of appliance Natural gas G20 Propane G31 Nominal heat input (Gross caloriﬁ...
Page 82 Bellﬁ res English Model : VERTICAL BELL LARGE Country : GB; Great Britain/IE; Ireland : GB; Great Britain/IE; Ireland Product identiﬁ cation no : 0063BL5625 : 0063BL5625 Type of appliance under CE-norm Category of appliance Natural gas G20 Propane G31 Nominal heat input (Gross caloriﬁ...
Page 83 Bellﬁ res English Model : VERTICAL BELL LARGE TUNNEL VERTICAL BELL SMALL Country : GB; Great Britain/IE; Ireland : GB; Great Britain/IE; Ireland Product identiﬁ cation no : 0063BL5625 : 0063BL5625 Type of appliance under CE-norm Category of appliance Natural gas G20 Propane G31 Nominal heat input (Gross caloriﬁ...
Page 84 Bellﬁ res English Model : VIEW BELL VERTICAL Country : GB; Great Britain/IE; Ireland : GB; Great Britain/IE; Ireland Product identiﬁ cation no : 0063BL5625 : 0063BL5625 Type of appliance under CE-norm Category of appliance Natural gas G20 Butane G30/Propane G31 3B/P Nominal heat input (Gross caloriﬁ...
Page 85: Replacement Parts List
Bellﬁ res English REPLACEMENT PARTS LIST When requesting service or ordering replacement parts, please quote the model type and serial number. All parts listed in this manual may be ordered from a Bellﬁ res dealer. Article no. Description 310995 Gas regulator block, BM 733 - 234484 (M9 Thermocouple connection) 301983 Nut Ø4 mm BM for pilot light pipe 301989...
Page 86 à 100 2,5 kg. gram gram gram Article no: 311011 311012 311003 321633 312914 311002 310937 Derby 311880 Derby II 311880 Jersey 311883 Flat Bell 311883 Topsham 311879 Topsham Tunnel 311884 York 311879 Kent 311879 Retro Bell Intermediate 311883...
Page 87 Appliance Log set Marble Marble pebbles pebbles set (white) set (grey) Embers with Vermiculite no 4 Log no Chips of Glow-effect black wood-set Anthracite ﬁ ltered 3 pieces Bag: 125 gr. Bag: 100 gr. Bag: 2,5 kg. Bag: 2,5 kg. Article no: xxxxxx 301863...
Page 88: Disposal Of Packaging And Appliance
Bellﬁ res English 10. DISPOSING OF PACKAGING AND APPLIANCE The appliance comes in recyclable packaging. This can include: • Cardboard • Wood • Plastic • Paper Such materials must be disposed of responsibly, in line with local regulations. Batteries should be disposed of as chemical waste. Batteries must be disposed of responsibly, in line with local regulations.
Page 89 Bellﬁ res English Instructions for use and installation instructions...
Page 90 INTERFOCOS B.V. HALLENSTRAAT 17 5531 AB BLADEL NEDERLAND E-mail: info@interfocos.nl Internet: www.interfocos.com 03 - 010509 - 322907...
