INSTRUCTIONS FOR USE &
MANUAL DAILY MAINTENANCE
HORIZON BELL SMALL
TUNNEL 3
Gas fi re with closed combustion system
Bellfi res wishes you many cosy evenings with your new Bellfi res gas fi re
This document is an essential part of your gas fi re.
Read it carefully before use of the gas fi re and keep it in a safe place!
Serial number:
Production date:
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Bellfires HORIZON BELL SMALLTUNNEL 3
Summary of Contents for Bellfires HORIZON BELL SMALLTUNNEL 3
- Page 1 INSTRUCTIONS FOR USE & MANUAL DAILY MAINTENANCE HORIZON BELL SMALL TUNNEL 3 Gas fi re with closed combustion system Bellfi res wishes you many cosy evenings with your new Bellfi res gas fi re This document is an essential part of your gas fi re. Read it carefully before use of the gas fi...
- Page 3 Bellfi res English BELLFIRES GAS FIRE WITH CLOSED COMBUSTION SYSTEM: Horizon Bell Small Tunnel 3 (HBST3) Instructions for use...
- Page 4 Bellfi res English Instructions for use...
-
Page 5: Table Of Contents
Bellfi res English CONTENTS Page 1. WARRANTY TERMS ................. 2. INSTRUCTIONS FOR USE ............... 3. USING THE APPLIANCE FOR THE FIRST TIME ........4. DAILY MAINTENANCE ................5. ANNUAL MAINTENANCE ................Instructions for use... - Page 6 Bellfi res English Instructions for use...
-
Page 7: Warranty Terms
Bellfi res English WARRANTY TERMS Interfocos Warranty terms Interfocos B.V. guarantees the quality of the supplied Bellfi res hearth and the quality of the materials used. All Bellfi res hearths are developed and manufactured according to the highest possible quality standards. If, despite all this, something should prove amiss with the Bellfi... - Page 8 Bellfi res English it has not be used or maintained according to the instructions for use; it has been changed, neglected or roughly treated; it has been damaged as a result of external causes (outside the hearth itself), for example, lightning strike, water damage or fi re; 3.2.
-
Page 9: Instructions For Use
Bellfi res English INSTRUCTIONS FOR USE INTRODUCTION Congratulations on your purchase of this modern Bellfi res gas fi re. This quality product will provide you with many years of enjoyment due to the fl ame effect and warmth that it provides. Please read the instructions for use carefully before using the appliance for the fi... - Page 10 Bellfi res English Never place fl ammable material on the ceramic log set. The fi lling of the main burner with embers, vermiculite granules, wood logs or pebbles may not under any circumstances be changed or added to. Do not place easily-fl ammable materials, such as nylon clothing or fl...
- Page 11 Bellfi res English 2.3.1 General Read these instructions carefully before lighting the fi re !! The appliance is opperated by radio remote control. This comprises a hand-held transmitter and a receiver. The receiver is part of the gas control block assembly. The receiver and the gas control block are behind the (white) panel door (operating unit) next to the appliance.
- Page 12 Bellfi res English Set the display • Connect the batteries. By simultaneously pressing OFF and (small fl ame), can be switched from °F (and 12 hour clock) to °C (and 24 hour clock), or vice versa. • The display will automatically return to mode after some time, but you may immediately return to mode by pressing the OFF button.
- Page 13 Bellfi res English Operating possibilities It is possible to use the remote control in 3 ways to operate the appliance: You can cycle through the menu with operating possibilities by repeatedly depressing the SET button. the selected starting time (P1 or P2 ) or stopping time (P1 or P2 ) is also shown.
- Page 14 Bellfi res English Operating the night temperature thermostat (Appliance is in the stand-by position and the pilot light is burning.) Automatic temperature regulation of the pre-set night temperature. The room temperature is measured and compared with the pre-set night temperature. The fl ame height is automatically regulated so as to reach the pre-set night temperature.
- Page 15 Bellfi res English Programming the timer: P1 and P2 • Select the desired mode of operation by pressing the SET button briefl y. • Press the SET button until P1 (heating period 1) and the time appear in the display. (The time indication fl ashes.) •...
- Page 16 Bellfi res English Connection Piezo Igniter (only for MANual control) ON/OFF Switch Operating Knob 8-wire Receiver Jack Motor-Knob Microswitch (in maximum position) Figure 3: Gas regulating block; Operating Knob in ON-position • Possible error messages: * 3x short audio signal, audible when the motor-knob operates: Receiver batteries need changing soon (having heard this signal, the appliance can be ignited another ten times approximately).
- Page 17 Bellfi res English • Press button (large fl ame) to increase the fl ame level and to turn on the burner from the stand-by position. (Pressing briefl y the (large fl ame) button gradually increases the fl ames to the high position.) Pressing the (large fl...
- Page 18 Bellfi res English 1 Hand-held transmitter: * Open the cover on the back of the transmitter. * Carefully remove the 9V battery and disconnect it from the contact. Do not pull the wires! * Connect the new battery and replace in the battery compartment. Close the cover. 2 Receiver: * Carefully pull the receiver assembly out of the compartment behind the (white) panel door.
- Page 19 Bellfi res English Igniting the fi re • Open the gas supply valve in the gas pipe to the fi re. • Switch the “O I” switch on the gas regulating block to the “I” position. • Turn the motor-knob on the gas regulating block completely to the right, in the OFF position.
-
Page 20: Using The Appliance For The First Time
Bellfi res English USING THE APPLIANCE FOR THE FIRST TIME The gas fi re is coated with a lacquer layer resistant to high temperature. During the fi rst hours of operation, the burning in of the lacquer may result in an unpleasant smell. This is harmless, however. -
Page 21: Annual Maintenance
Bellfi res English ANNUAL MAINTENANCE It is essential that the appliance, the complete concentric fl ue system (where possible) and the outlet are cleaned and inspected annually by a recognised fi tter/gas specialist. The safe operation of the appliance will thus remain guaranteed. - Page 22 Bellfi res English Instructions for use...
- Page 24 Your Bellfi res dealer 02 - 011212 - 331799...
