TECHNICAL DETAILS/REGULATIONS

National installation regulations:
• Gas safety installation and use regulations 1998 plus all relevant
safety and building regulations concerning fi re installation
• Document J: Combustion appliances and fuel storage systems
Model
Gas
Country
Product identifi cation no
Type of appliance under CE-norm
Category of appliance
Nominal heat input
(Gross calorifi c value)
Nominal heat output
Effi ciency class
NOx-class
Gas rate (max.)
Supply pressure
Burner pressure (max.) Hot
Burner pressure (max.) Cold
Burner pressure (min.)
Primary air inlet burner Rear
Primary air inlet burner Front
Gas regulator block (remote control)
Main burner
Main burner injector Rear
Main burner injector Front
Pilot light burner
Pilot light burner injector
Gas connection
Concentric fl ue system connection
66
: VIEW BELL XXL 3 CF (Centre Fire)
: NATURAL GAS
: GB; Great Britain/IE; Ireland
: 0063CM3684
: C / C / C
11 31 91
: I natural gas G20
2H
: 14.2 kW
: 10.9 kW
: 1 (85%)
: 5
: 1.36 m 3 /hr.
s
: 20.0 mbar
: 12.1 mbar(*)
: 11.4 mbar(**)
: 2.5 mbar(***)
: 1x Ø10.0 mm
: 1x Ø10.0 mm
: Mertik GV 60
: Centre Fire 1354x130 mm
: no 225 (= 1x Ø2.25 mm)
: no 225 (= 1x Ø2.25 mm)
: SIT 0.145.019
: no 36 (SIT 0.977.091)
: 3/8" G / Ø12 mm
: Ø130 mm - Ø200 mm
English
: BUTANE / PROPANE
: GB; Great Britain/IE; Ireland
: 0063CM3684
: C / C / C
11 31 91
: I butane/propane G30/G31
3B/P
: Butane (G30) : 13.0 kW
Propane (G31) : 11.0 kW
: 8.5 - 10.0 kW
: 1 (85%)
: 5
: Butane (G30) : 960 gr/hr.
Propane (G31) : 790 gr/hr.
: Butane (G30) : 37.0 mbar
Propane (G31) : 37.0 mbar
: 29.0 mbar(*)
: 29.0 mbar(**)
: 4.0 mbar(***)
: 1x Ø20.0 +corner mm +
2x Ø5.0 mm
: 1x Ø20,0 +corner mm +
2x Ø5.0 mm
: Mertik GV 60
: Centre Fire 1354x130 mm
: no 130 (= 1x Ø1.30 mm)
: no 130 (= 1x Ø1.30 mm)
: SIT 0.145.019
: no 23 (SIT 0.977.150)
: 3/8" G / Ø12 mm
: Ø130 mm - Ø200 mm
