Bellfires DERBY LARGE 3 PF Supplement, Installation Instructions & Maintenance Manual

"premium fire", with a closed combustion system
Hide thumbs

Advertisement

Quick Links

"PREMIUM FIRE"
SUPPLEMENT
INSTALLATION INSTRUCTIONS &
MAINTENANCE MANUAL
DERBY LARGE 3 PF
DERBY SMALL 3 PF
TOPSHAM LARGE 3 PF
YORK LARGE 3 PF
YORK SMALL 3 PF
VIEW BELL DERBY 3 PF
VIEW BELL SMALL 3 PF
VIEW BELL TOPSHAM 3 PF
VIEW BELL YORK 3 PF
CORNER BELL DERBY 3 L/R PF
CORNER BELL SMALL 3 L/R PF
CORNER BELL TOPSHAM 3 L/R PF
CORNER BELL YORK 3 L/R PF
Gas fi replace with a closed combustion system
Bellfi res wishes you many cosy evenings with your new Bellfi res gas fi re
This document is an essential part of your gas fi re. Read it carefully before
installation and use of the gas fi re and keep it in a safe place!
Serial number:
Production date:

Advertisement

loading
Need help?

Need help?

Do you have a question about the DERBY LARGE 3 PF and is the answer not in the manual?

Questions and answers

Related Manuals for Bellfires DERBY LARGE 3 PF

Summary of Contents for Bellfires DERBY LARGE 3 PF

  • Page 1 "PREMIUM FIRE" SUPPLEMENT INSTALLATION INSTRUCTIONS & MAINTENANCE MANUAL DERBY LARGE 3 PF DERBY SMALL 3 PF TOPSHAM LARGE 3 PF YORK LARGE 3 PF YORK SMALL 3 PF VIEW BELL DERBY 3 PF VIEW BELL SMALL 3 PF VIEW BELL TOPSHAM 3 PF...
  • Page 3 English BELLFIRES GAS FIREPLACE WITH CLOSED COMBUSTION SYSTEM: Derby Large 3 PF (Premium Fire) (DYL3 PF) Derby Small 3 PF (Premium Fire) (DYS3 PF) Topsham Large 3 PF (Premium Fire) (TSL3 PF) York Large 3 PF (Premium Fire) (YKL3 PF)
  • Page 4 English Installation instructions...

  • Page 5: Table Of Contents

    English SUPPLEMENT TO THE CONTENTS Page INSTALLATION INSTRUCTIONS ............. 1.7.6 Placing the ceramic log set, ‘fi re glass’, embers and decorative ash ............. 4A. DISASSEMBLY AND ASSEMBLY OF THE BURNERS AND MESH GRATES REPLACING THE AMBIENT LIGHTS ............TECHNICAL DETAILS AND REGULATIONS ..........REPLACEMENT PARTS LIST ..............
  • Page 6 English Installation instructions...

  • Page 7: Installation Instructions

    English SUPPLEMENT TO CHAPTER 1: INSTALLATION INSTRUCTIONS Page 56: Figure 23A: Module (Light) The appliance is fi tted with a 230V AC connection and may only be connected to an earthed socket. The appliance has ambient lighting. Electrical connections and batteries: Appliance Module (light) 230V AC...
  • Page 8 English Upon delivery of the appliance, the electrical connections of the gas regulator block and the receiver are already assembled. The Module(Light) is separately delivered with the appliance. This component is to be electrically connected during the installation according to the following Figure 23B and 23C. Attach the earth cable (yellow/green) to a metal part on the inside of the operating unit, with the help of the existing screw.
  • Page 9 English Figure 23C: Connecting 5 wire cable 6VDC on MODULE connection of the receiver Built-in operating unit Module(Light) Receiver Attach the Earth cable (yellow / green) to a metal part on the inside of the operating unit. Rating plate Gas regulator block Figure 23D: Built-in operating unit Position Receiver, Module(Light) and Gas regulator block...

  • Page 10: 1.7.6 Placing The Ceramic Log Set, 'Fi Re Glass', Embers And Decorative Ash

    English Page 64: 1.7.6 Placing the ceramic log set, ‘fi re glass’, embers and decorative ash. For appliance fi tted with the "Premium Fire" (PF) double burner: The construction of the ceramic log set, "fi re glass", embers and decorative ash for an appliance with a "Premium Fire (PF) NATURAL GAS double burner is the same as for a Premium Fire (PF) PROPANE/BUTANE double burner.
  • Page 11 English • "Fire glass Black • "Fire glass Dark Amber" • Embers; E Installation instructions...
  • Page 12 English • Decorative ash; A Important : • Place the log set, ‘fi re glass’, embers and decorative ash, carefully on and around the main burners, as indicated by the specifi cations mentioned in this chapter. • Do not place "fi re glass", embers or decorative ash on or against the pilot light burner.
  • Page 13 English 1.7.6.1 Ceramic log set + ‘fi re glass’ + embers + decorative ash IMPORTANT: Check the presence of the three burner fi xing bolts. See photo. Check the operation of the ambient lighting/dimmer with the remote control. See operating instructions; Operation light / dimmer If necessary repair the ambient lighting.
  • Page 14 English Place burner log No. 16 carefully on the burner - right. Check fi rst if the "Arrow", on the underside of the log, is pointing up. Burner log No. 16 = Art. no. 340021 (legible on the underside of the log) Check that the underside of the log has free space on both end faces of ±...
  • Page 15 English Place burner log No. 14 carefully on the burner - left. Check fi rst if the "Arrow", on the underside of the log, is pointing up. Burner log No. 14 Art. no. 340019 (legible on the underside of the log) Check that the underside of the log has free space on both end faces of ±...
  • Page 16 English Place burner log No. 15 carefully on the burner - middle (with the pilot light). Burner log No. 15 = Art. no. 340020 (legible on the underside of the log) Check that the pilot light remains visible. Installation instructions...
  • Page 17 English Place the charcoal part No. 23 (= 1x Art. no. 340028) under the Right burner, around the venturi. Place the charcoal part No. 24 (= 1x Art. no. 340029) under the Left burner, around the venturi. Installation instructions...
  • Page 18 English Sprinkle the ‘Fire glass Dark Amber’ evenly on the mesh grate, around the burners. Note: Put no "fi re glass" on or against the pilot light burner! Note: Put no ‘fi re glass’ under burner logs No. 14, 15 and 16, where these are supported by the mesh grate.
  • Page 19 English Set the light intensity of the ambient lighting/dimmer to max. on the remote control. See operating instructions; Operation light / dimmer Check that the "fi re glass" is distributed evenly and that the light intensity is the same everywhere. Adjust the distribution of the "fi re glass" if necessary. Place log No.
  • Page 20 English Place charcoal part No. 21 (= 1x Art. no. 340026). Place log No. 17 (= 1x Art. no. 340022). Place branch No. 19 (= 1x Art. no. 340024). Installation instructions...
  • Page 21 English Place branch No. 20 (= 1x Art. no. 340025). Place charcoal part No. 22 (= 1x Art. no. 340027). Installation instructions...
  • Page 22 English Place 3x charcoal parts No. 25 (= 3x Art. no. 340030). Break the embers supplied in half and distribute the parts along the side on the grate (around the mesh grate). Note: Do not place any embers on the mesh grate. Embers will block the light! Note: Put no embers on or against the pilot light burner! Installation instructions...
  • Page 23 English Decorative ash: Carefully distribute a small amount of decorative ash over the entire bottom. Check that the pilot light burner is easily visible from the right hand side of the log set. Pilot light position Pilot light Pilot light Installation instructions...
  • Page 24 English The ceramic log set construction, "fi re glass", embers and decorative ash is completed. Figure 24: Log set Set-up of Natural gas and propane/butane burner - "Premium Fire" IMPORTANT: • Do not put any "fi re glass" or embers in front of the pilot light burner •...

  • Page 25: Disassembly And Assembly Of The Burners And Mesh Grates Replacing The Ambient Lights

    English SUPPLEMENT TO CHAPTER 4: DISASSEMBLY / ASSEMBLY OF THE GLASS. DISASSEMBLY AND ASSEMBLY OF THE BURNERS AND MESH GRATES REPLACING THE AMBIENT LIGHTS Carefully remove the log set, burners and mesh grates in the following order: Complete log set ‘Premium Fire’ Burner log No.
  • Page 26 English Log No. 17 Burner log No. 14 Branch No. 19 Installation instructions...
  • Page 27 English Burner log No. 15 Branch No. 20 Log No. 18 Installation instructions...
  • Page 28 English Log No. 21 Charcoal part No. 24 Charcoal part No. 23 Charcoal part No. 25 (3x) Installation instructions...
  • Page 29 English The three burners are all fi xed with just one hexagonal bolt. When unscrewing the burner fi xing bolts, use socket spanner no. 7. Disassemble and remove the burner - right. Installation instructions...
  • Page 30 English 14. Disassemble and remove the burner - middle. Disassemble and remove the burner - left. Installation instructions...
  • Page 31 English Use working gloves when removing the mesh grates. 16. Carefully remove the mesh grate - left. 17. Carefully remove the mesh grate - right. Installation instructions...
  • Page 32 English Clean the light compartment and gas injectors with a vacuum cleaner. Replacing the ambient lights. Only use original Bellfi res ambient lamps: Art. no. 333748: Ambient lamp; 230-240V - 25W - E14 - 300˚C. - Colour: Amber Remove the plug of the appliance from the socket. Installation instructions...
  • Page 33 English Carefully unscrew the defective lamp from the fi tting. Carefully screw the new lamp into the fi tting. Screw the ambient lamps fully into the fi tting! Installation instructions...
  • Page 34 English 22. Replace the plug of the appliance into the socket. 23. Check the operation of the ambient lighting/dimmer with the remote control. See operating instructions; Operation light / dimmer Carefully place the mesh grates, burners and log set in the following order: Use working gloves when placing the mesh grates.
  • Page 35 English Sprinkle the "Fire glass Dark Amber" on the rear of the mesh grates. Do not let any "fi re glass" fall in the grate apertures. Installation instructions...
  • Page 36 English Fix each burner with the hexagon bolt supplied. Use socket spanner no. 7 to do this. Not mounting these fi xing bolts can give rise to a dangerous situation. Prevent this at all costs! Place and assemble the burner - left. Press the burner down fi...
  • Page 37 English Make sure that no “fire glass” parts are under the lowest point of the burner! The lowest point of the burner must be able to float above the mesh grate. Place and assemble the burner - right. Press the burner down fi rmly, and mount the fi xing bolt. Installation instructions...
  • Page 38 English Place and assemble the burner - middle. Press the burner down fi rmly, and mount the fi xing bolt. Place the Ceramic log set, ‘fi re glass’, embers and decorative ash, as indicated in chapter 1.7.6.1 Installation instructions...

  • Page 39: Technical Details And Regulations

    • Gas safety installation and use regulations 1998 plus all relevant safety and building regulations concerning fi re installation • Document J: Combustion appliances and fuel storage systems Model : DERBY LARGE 3 PF (PREMIUM FIRE) DERBY SMALL 3 PF (PREMIUM FIRE)
  • Page 40 English Model : DERBY LARGE 3 PF (PREMIUM FIRE) DERBY SMALL 3 PF (PREMIUM FIRE) TOPSHAM LARGE 3 PF (PREMIUM FIRE) YORK LARGE 3 PF (PREMIUM FIRE) YORK SMALL 3 PF (PREMIUM FIRE) VIEW BELL DERBY 3 PF (PREMIUM FIRE)

  • Page 41: Replacement Parts List

    English SUPPLEMENT CH. 8: REPLACEMENT PARTS LIST Article no. Description Main burner "Premium Fire" 600 x 240 mm Natural gas G20 / Butane/Propane G30/G31 3..G20: Ø6.0 mm Left-Rear Ø3.5 mm Left-Front Ø6.0 mm Middle-Front Ø6.0 mm Right-Rear Ø3.5 mm Right-Front 3..
  • Page 42 340024 340025 340026 340027 340028 340029 340030 * Derby Large 3 PF * Derby Small 3 PF * Topsham Large 3 PF * York Small 3 PF Number * Corner Bell Topsham 3 L/R PF * View Bell Topsham 3 PF...
  • Page 44 Your Bellfi res dealer 03 - 060617 - 340641...
