Thermocouple
Pilot light pipe
Ø4 mm Flex.
Thermocouple
interrupter
Figure 16: Gas regulator block and gas valve: Gas and thermocouple connections
Pilot Gas Adjustment Screw
(Pierce the housing with
a small screwdriver)
Figure 17: Gas regulator block - Front
Bellfi res
GAS LINE INSTALLATION
8 Wire connecting
cable receiver
43
Gas pipe
"rear burner"
Ø8 mm Flex.
Gas valve
"rear burner"
Gas pipe
"front burner"
Ø8 mm Flex.
Gas supply
connection
⅜" NPT
Gas regulator block
Adjustment Screw
Maximum
Burner pressure
Microswitch
Installation instructions
Motor-knob
