Bellfires View Bell Medium 3 CF Installation Manual page 26

METAL-FAB - Sure-Seal Direct Vent Products 4" x 6.5" -
Available approved components:
METAL-FAB - Sure-Seal Direct Vent Products Concentric (= Co-axial) direct vent system
Size Diam. (in.) : 4" x 6.5"
Material Type : 0.012" 430 stainless steel inner wall
0.018" galvanized steel outer wall
Item no. Descrip! on
1 Bellfi res Adapter: 5⅛" x 7⅞" to 4" x 6.5" Metal-Fab
2 Ver# cal Termina# on - Termina# on Cap
6 6" Pipe Straight Length assembly
8 12" Pipe Straight Length assembly
9 18" Pipe Straight Length assembly
10 24" Pipe Straight Length assembly
11 36" Pipe Straight Length assembly
12 48" Pipe Straight Length assembly
14 Adjustable Length 3"-10"
19 Elbow 45°
21 Elbow 90°
23 Wall support
26 Firestop
- Support Plate
- Decora# ve Cover Plate
28 Roof Flashing, Roof Pitch ±30˚
29 Roof Flashing, Roof Pitch Steep ±45˚
- Roof Flashing, Roof Pitch Extra Steep ±60˚
30 Roof Flashing, Flat Roof
33 Storm Collar
- Painted Roof Support
Bellfi res
VENT INSTALLATION
26
METAL-FAB Part no.
54DBA
4DVT
4D6
4D12
4D18
4D24
4D36
4D48
4DAL
4D45L
4D90L
4DWS
4DFS
4DSP
4DCP
4DF
4DF-S
4DF-ES
4DF-FR
4DSC
4DRS
Installation instructions
