SELKIRK - DIRECT-TEMP Direct Vent Products 4" x 6⅝" -
Available approved components:
SELKIRK – DIRECT-TEMP Direct Vent Products Concentric (= Co-axial) direct vent system
Size Diam. (in.) : 4" x 6⅝"
Material Type : 0.012" 304 stainless steel inner wall
0.018" galvanized steel outer wall
Item no. Descrip! on
1 Bellfi res Adapter: 5⅛" x 7⅞" to 4" x 6⅝" Direct Temp
2 Ver# cal Termina# on
6 DT - 6" Pipe
7 DT - 9" Pipe
8 DT - 12" Pipe
9 DT - 18" Pipe
10 DT - 24" Pipe
11 DT - 36" Pipe
12 DT - 48" Pipe
14 Adjustable Length 4-10"
16 Telescopic Length 14-22"
17 Telescopic Length 38-70"
19 Elbow 45°
21 Elbow 90°
23 Wall Support/Band
24 Ceiling Support
25 Cathedral Ceiling Support Box
26 Firestop Spacer
27 A$ c Insula# on Shield
- Off set Support
28 Roof Flashing, Adjustable 0/12 to 6/12
29 Roof Flashing, Adjustable 6/12 to 12/12
30 Roof Flashing, Rubber Boot
33 Storm Collar
- Trim Plate
Bellfi res
VENT INSTALLATION
24
SELKIRK Part no.
4DT-AAB
4DT-VT
4DT-06
4DT-09
4DT-12
4DT-18
4DT-24
4DT-36
4DT-48
4DT-AJ12
4DT-TL 14
4DT-TL 38
4DT-EL45
4DT-EL90S
4DTWS/B
4DT-CS
4DT-CCS
4DT-FS
4DT-AIS
4DT-OS
4DT-AF6
4DT-AF12
URBAK
4DT-SC
4DT-TP
