View Bell Medium 3 CF

Direct Vent Gas Fireplace

Installation manual

WARNING

A barrier designed to reduce the risk of burns from the

hot viewing glass is provided with this appliance and

shall be installed for the protection of children and other

at-risk individuals.

WARNING:

followed exactly, a ﬁ re or explosion may result causing property damage,

personal injury or loss of life.

- Do not store or use gasoline or other ﬂ ammable vapors and liquids in

the vicinity of this or any other appliance.

- WHAT TO DO IF YOU SMELL GAS:

•

Do not try to light any appliance.

•

Do not touch any electrical switch; do not use any phone in your

building.

•

Immediately call your gas supplier from a neighbor's phone.

Follow the gas supplier's instructions.

•

If you cannot reach your gas supplier, call the ﬁ re department.

- Installation and service must be performed by a qualiﬁ ed installer,

service agency or the gas supplier.

This appliance may be installed in an aftermarket, permanently located,

manufactured home (USA only) or mobile home, where not prohibited by

local codes. This appliance is only for use with the types of gas indicated

on the rating plate. A conversion kit is supplied with the appliance.

HOT GLASS WILL

CAUSE BURNS.

DO NOT TOUCH GLASS

UNTIL COOLED.

NEVER ALLOW CHILDREN

TO TOUCH GLASS.

WARNINGS

If the information in these instructions are not

INSTALLER:

Leave this manual with

the appliance.

CONSUMER:

Retain this manual for

future reference.

Table of Contents

Need help?

Do you have a question about the View Bell Medium 3 CF and is the answer not in the manual?

Questions and answers

Summary of Contents for Bellfires View Bell Medium 3 CF

Page 1 View Bell Medium 3 CF Direct Vent Gas Fireplace Installation manual WARNING INSTALLER: HOT GLASS WILL Leave this manual with CAUSE BURNS. the appliance. DO NOT TOUCH GLASS UNTIL COOLED. NEVER ALLOW CHILDREN TO TOUCH GLASS. CONSUMER: A barrier designed to reduce the risk of burns from the...
Page 3: Table Of Contents
CONTENTS Page IMPORTANT SAFETY INSTRUCTIONS ............CODE APPROVAL ................... PRE INSTALLATION INSTRUCTIONS ............GENERAL ....................CONCENTRIC FLUE SYSTEMS ............. INCLUDED WITH THE APPLIANCE ............OPTIONS AND ACCESSORIES .............. CLEARANCES ....................VENT INSTALLATION ..................POSITIONING THE APPLIANCE ..............GAS LINE INSTALLATION ................BUILDING IN THE APPLIANCE ...............
Page 4 Bellﬁ res Installation instructions...
Page 5: Important Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS WARNING: Improper installation, adjustment, alteration, services or maintenance can cause serious injury or property damage. Refer to this manual. SAVE THESE INSTRUCTIONS Make yourself fully aware of all the following instructions and the many features of the Bellﬁ res direct vent gas ﬁ replace appliance. INSTALLER: Leave this manual with the appliance CONSUMER: Retain this manual for future reference.
Page 6 IMPORTANT SAFETY INSTRUCTIONS Keep the area around your appliance clear of combustible materials, gasoline and other ﬂ ammable vapor and liquids. Do not place embers, vermiculite granules or wood logs against the pilot light burner. Make sure that the pilot ﬂame can burn at all times freely over the main burner.
Page 7 IMPORTANT SAFETY INSTRUCTIONS 20. Keep control compartments, burners and circulating air passages clean. More frequent cleaning may be needed due to excessive lint and dust. Turn off the gas valve and appliance (OFF on remote control) before cleaning the appliance. 21.
Page 8: Code Approval
VENTED GAS FIREPLACES in the USA and Canada as follows: LISTED VENTED GAS FIREPLACES View Bell Medium 3 CF tested to: - ANSI Z21. 88 - 2009 / CSA 2.33 - 2009 Vented Gas Fireplace Heaters - ANSI Z21.88a - 2012 / CSA 2.33a - 2012 - Addenda 1 to ANSI Z21.88 - 2009 / CSA 2.33 - 2009...
Page 9: Pre Installation Instructions
PRE INSTALLATION INSTRUCTIONS WARNING: Due to high temperatures, the appliance should be located out of trafﬁ c and away from furniture and draperies. GENERAL This ‘direct vent’ gas appliance must be installed by a qualiﬁ ed installer in accordance with local building codes, or in the absence of local codes, with the current CAN/CSA- B149.1 or .2 Installation Code (in Canada) or the current National Fuel Gas Code Z223.1-NFPA 54 when installed in the United States.
Page 10: Concentric Flue Systems
INCLUDED WITH THE APPLIANCE Set documentation Instructions for use Installation instructions Attributes Barrier Ceramic log set Propane conversion kit View Bell Medium 3 CF N.B. If any part is missing, please contact your dealer. Bellﬁ res Installation instructions...
Page 11: Options And Accessories
Mantle iron VWBM3 337810 High altitude kit 2 000 - 4 500 ft View Bell Medium 3 CF (Natural gas and Propane gas) M&G DuraVent - Direct Vent Pro concentric ﬂ ue system See component summary SELKIRK - DIRECT-TEMP - Direct Vent Products concentric ﬂ ue...
Page 12: Clearances
CLEARANCES WARNING: Follow these instructions carefully to ensure safe installation. Failure to follow instructions exactly can create a ﬁ re hazard. UNIT MUST SIT ON NON COMBUSTABLE SURFACE The appliance must be installed on a non-combustible ﬂ oor. If installed on, for example, carpet or vinyl ﬂ...
Page 13 CLEARANCES Clearances to combustible material Always place a non-combustible insulation plate (false back wall) with a thickness of min. 1" (2.54 cm) between the appliance and the rear wall and the side wall according to ﬁ gure 1. Minimum clearances to combustible material must be maintained. (See also ﬁ...
Page 14 CLEARANCES Clearance to non-combustible material Always place a non-combustible insulation plate (false back wall), at least ½" (12 mm) thick between the appliance and a non-combustible rear and side wall. Maintain a free space of at least ¾" (2 cm) on either side of the insulation plate. Minimum clearances as shown in ﬁ...
Page 15 CLEARANCES Ventilation Ventilate the ﬁ replace/chimney breast: • all spaces between the appliance and the insulation plates • all spaces between the insulation plates an all surrounding walls by allowing vents above. Minimal required net vent openings above must be total 46 sq ins (300 cm This can be done by ventilation openings or grills.
Page 16 CLEARANCES Mantel clearances Any mantel piece made of combustible material should be placed at least 2" from the side and top of the ﬁ replace opening. Minimum mantel clearances are shown in ﬁ gure 3 to 5. Non combustible Insulation plate / board 12"...
Page 17: Side View
CLEARANCES Depth of mantel [inch] Combustible mantel piece Non-combustible material Insulation plate / board Top of ﬁ replace opening Glass front appliance Side view Figure 4: Top mantel clearances Bellﬁ res Installation instructions...
Page 18 Depth of mantel [inch] Depth of mantel [inch] Non-combustible material Insulation plate / board Side of Side of ﬁ replace ﬁ replace opening opening Combustible Combustible mantel piece mantel piece Top view...
Page 19 CLEARANCES 12" 12" (30 cm) (30 cm) Fireplace VIEW BELL MEDIUM 3 12" (30 cm) Hearth • Install a non combustible Do not place furniture hearth (ﬂ oor stone) when or other objects in this the underside of the glass space in front of the is less then 4"...
Page 20 Canadian Installations US Installations A= Clearance above, grade, veranda, porch, deck or balcony 12 in (30 cm) 12 in (30 cm) B= Clearance to window, or door that may be opened 12 in (30 cm) 9 in (23 cm) Clearance to permanently closed window 12 in (30 cm) 9 in (23 cm) Vertical clearance to ventilated sofﬁ...
Page 21 Canadian Installations US Installations E= Clearance to unventilated sofﬁ t 12 in (30 cm) 12 in (30 cm) F= Clearance to outside corner 20 in (51 cm) 20 in (51 cm) G= Clearance to inside corner 20 in (51 cm) 20 in (51 cm) H= Clearance to each inside of center line extended above meter / regulator 3 ft (91 cm) within a height...
Page 22: Vent Installation
VENT INSTALLATION M&G DuraVent - DIRECT VENT PRO 4" x 6⅝" - Available approved components: M&G DuraVent - Direct Vent Pro Concentric (= Co-axial) direct vent system Size Diam. (in.) : 4" x 6⅝" Material Type : 0.020" aluminum inner wall - 0.018" galvanized steel outer wall Item no.
Page 23 VENT INSTALLATION M&G DuraVent - DIRECT VENT PRO 5" x 8" - Available approved components: M&G DuraVent - Direct Vent Pro Concentric (= Co-axial) direct vent system Size Diam. (in.) : 5" x 8" Material Type : 0.020" aluminum inner wall - 0.018" galvanized steel outer wall Item no.
Page 24 VENT INSTALLATION SELKIRK - DIRECT-TEMP Direct Vent Products 4" x 6⅝" - Available approved components: SELKIRK – DIRECT-TEMP Direct Vent Products Concentric (= Co-axial) direct vent system Size Diam. (in.) : 4" x 6⅝" Material Type : 0.012" 304 stainless steel inner wall 0.018"...
Page 25 VENT INSTALLATION SELKIRK - DIRECT-TEMP Direct Vent Products 5" x 8" - Available approved components: SELKIRK - DIRECT-TEMP Direct Vent Products Concentric (= Co-axial) direct vent system Size Diam. (in.) : 5" x 8" Material Type : 0.012" 304 stainless steel inner wall 0.018"...
Page 26 VENT INSTALLATION METAL-FAB - Sure-Seal Direct Vent Products 4" x 6.5" - Available approved components: METAL-FAB - Sure-Seal Direct Vent Products Concentric (= Co-axial) direct vent system Size Diam. (in.) : 4" x 6.5" Material Type : 0.012" 430 stainless steel inner wall 0.018"...
Page 27 VENT INSTALLATION METAL-FAB - Sure-Seal Direct Vent Products 5" x 8" - Available approved components: METAL-FAB – Sure-Seal Direct Vent Products Concentric (= Co-axial) direct vent system Size Diam. (in.) : 5" x 8" Material Type : 0.012" 430 stainless steel inner wall 0.018"...
Page 28 VENT INSTALLATION CONCENTRIC FLUE SYSTEM IMPORTANT: • The direct vent gas appliances have been approved in combination with the components of the concentric ﬂ ue systems listed in this installation manual, according to the ANSI / CSA standards for gas appliances and may therefore be used only with these components.
Page 29 VENT INSTALLATION Vertical concentric ﬂ ue system in cold climates In cold climate conditions where temperatures go below 14°F (-10°C ), we recommend that the chase be insulated and where the concentric ﬂ ue pipe enters into the attic space that the pipe be wrapped with a non-combustible insulation sleeve.
Page 30 VENT INSTALLATION RIGID CONCENTRIC FLUE 4" x 6⅝" SYSTEM CONNECTION POSSIBILITIES Appliance: Concentric ﬂ ue connection 5⅛" x 7⅞" 2, 3, 4, 5 6 to 17 2, 3, 28, 29 4, 5 6 to 17 101 + 140 (or 1) Gas appliance Item descriptions: see Vent Installation...
Page 31 VENT INSTALLATION RIGID CONCENTRIC FLUE 4" x 6⅝" SYSTEM CONNECTION POSSIBILITIES Appliance: Concentric ﬂ ue connection 5⅛" x 7⅞" 2, 3, 4, 5 28, 29 18, 19, 20, 21 6 to 17 101 + 140 (or 1) Gas appliance Item descriptions: see Vent Installation Page 22-27 Assemble restriction plate:...
Page 32 VENT INSTALLATION FLEXIBLE CONCENTRIC FLUE 4" x 6⅝" SYSTEM CONNECTION POSSIBILITIES Appliance: Concentric ﬂ ue connection 5⅛" x 7⅞" 2, 3, 4, 5 6 to 17 101 + 140 (or 1) Item descriptions: Gas appliance see Vent Installation Page 22-27 Assemble restriction plate: Appliance: Distance Y...
Page 33 VENT INSTALLATION FLEXIBLE CONCENTRIC FLUE 4" x 6⅝" SYSTEM CONNECTION POSSIBILITIES Appliance: Concentric ﬂ ue connection 5⅛" x 7⅞" 2, 3, 4, 5 6 to 17 101 + 140 (or 1) Gas appliance Item descriptions: see Vent Installation Page 22-27 Assemble restriction plate: Appliance: Distance Y...
Page 34 VENT INSTALLATION RIGID CONCENTRIC FLUE 5" x 8" SYSTEM CONNECTION POSSIBILITIES and with wall outlet 5" x 8" Appliance: Concentric ﬂ ue connection 5⅛" x 7⅞" 102 to 105 106 to 117 Item descriptions: Gas appliance see Vent Installation Page 22-27 Assemble restriction plate: Appliance: Distance Y...
Page 35 VENT INSTALLATION RIGID CONCENTRIC FLUE 5" x 8" SYSTEM CONNECTION POSSIBILITIES and with wall outlet Ø5" x Ø8" Appliance: Concentric ﬂ ue connection 5⅛" x 7⅞" 102 to 105 106 to 117 Gas appliance Item descriptions: see Vent Installation Page 22-27 Assemble restriction plate: Appliance: Distance Y...
Page 36: Positioning The Appliance
POSITIONING THE APPLIANCE IMPORTANT: • The appliance must be constructed on a sufﬁ ciently solid ﬂ oor that can bear the weight of the appliance. • Ensure a free space of at least 0.4 in (1 cm) between the bottom of the appliance and the ﬂ...
Page 37 POSITIONING THE APPLIANCE Figure 13: Appliance installed in ventilated chimney breast / Enclosure Horizontal outlet of the ﬂ ue gas exhaust /combustion air supply via the wall. • Fitted with the accessory: high adjustable feet 1 Inlet opening (appliance) convection air for chimney breast/Enclosure 2 Natural convection in the chimney breast/Enclosure 3 Outlet opening (chimney breast/Enclosure) convection air.
Page 38 POSITIONING THE APPLIANCE Figure 14: Appliance installed in ventilated chimney breast / Enclosure Vertical outlet of the ﬂ ue gas exhaust / combustion air supply via the roof. • Fitted with the accessory: high adjustable feet 1 Inlet opening (appliance) convection air for chimney breast / Enclosure 2 Natural convection in the chimney breast / Enclosure 3 Outlet opening (chimney breast/Enclosure) convection air.
Page 39 POSITIONING THE APPLIANCE When ﬁ tting the appliance, it can be levelled with the adjustable feet. These adjustable feet can be reached via the openings (4x), after removing the protective covers, in the corners of the ﬂ oor of the combustion chamber. The ﬂ oor of the combustion chamber can be reached after the window and the grill around the burner have been removed (see Chapter: “DISMANTLING / ASSEMBLING OF THE GLASS”).
Page 40 POSITIONING THE APPLIANCE • Position the gas supply pipe such that it can be easily mounted after installation. Because the control system is outside the appliance, the gas pipe must lead to where the operating unit (built in), the gas regulator block (and the receiver) assembly are ﬁ...
Page 41: Gas Line Installation
GAS LINE INSTALLATION The appliance is supplied with a built-in operating unit. 9.7” Operating unit Frame with door (white) Figure 14: Operating unit Remove the decorative edging and door of the operating unit. Fit the separate operating unit, where the gas regulator block and receiver will be placed, on MAXIMUM 20"...
Page 42 GAS LINE INSTALLATION The gas line connection can be made using ½” rigid tubing or an approved ﬂ ex connector. Since some municipalities have additional local codes it is always best to consult your local authorities and the current edition of the National Fuel Gas Code ANSI.Z223.1, NFPA54.
Page 43 GAS LINE INSTALLATION Gas pipe “rear burner” Ø8 mm Flex. Thermocouple Gas valve “rear burner” Pilot light pipe Ø4 mm Flex. Thermocouple Gas pipe interrupter “front burner” Ø8 mm Flex. Gas supply connection ⅜” NPT Gas regulator block Figure 16: Gas regulator block and gas valve: Gas and thermocouple connections Pilot Gas Adjustment Screw Adjustment Screw (Pierce the housing with...
Page 44 GAS LINE INSTALLATION Adjustment Screw Minimum Burner pressure Inlet Pressure Tap Outlet Pilot light Pressure Tap connection Thermocouple interrupter Gas supply connection connection Gas connection for Gas connection for gas valve to the “front burner” to the “rear burner” Figure 18: Gas regulator block - Rear Thermocouple Thermocouple voltage / current...
Page 45 GAS LINE INSTALLATION RESET button AUX: Electrical connection for gas valve “rear burner” Figure 20: Receiver - AUX connection - RESET button Bellﬁ res Installation instructions...
Page 46: Building In The Appliance
BUILDING IN THE APPLIANCE Connecting the concentric ﬂ ue Assemble the concentric direct vent system according to one of the examples in ﬁ gure 7 to 12 inclusive. Make sure that all connections are completely gas tight. Building in the appliance Remove the front of the casing, if applicable.
Page 47 BUILDING IN THE APPLIANCE Mantle iron (option). The optional mantle iron is intended for supporting the brickwork above the appliance. The mantle iron must rest on the brickwork on both sides so that upward building is possible. Level the mantle iron with the supplied bar set. Keep a clearance of 0.1"...
Page 48 BUILDING IN THE APPLIANCE Fix the mantle iron to the rear wall with the bar set. Place the draw bars at an angle of about 60° (between the appliance and the wall). Level the mantle iron with the tension sleeves. 0.1"...
Page 49 BUILDING IN THE APPLIANCE DO NOT COVER Do not cover the top side of the appliance with (built-in) materials. Checking the gas connection After connection of the gas supply, check once again that all connections are completely gas tight using soapy water or a leak tester. Once the ﬁ...
Page 50: Placing Of Ceramic Log Set
PLACING OF CERAMIC LOG SET The appliance is supplied with a ceramic log set, embers and vermiculite granules. IMPORTANT: • Carefully place the chips of wood/embers/vermiculite granules and log set, on and around the main burner according to the directions in this chapter. •...
Page 51 PLACING OF CERAMIC LOG SET WARNING: Embers and vermiculite granules should not block the large burner openings (Centre ﬁ re burner - 0.62 in (16 mm)). Embers and vermiculite must not be placed next to the pilot light burner. 4. Place the ceramic logs on the burner as shown in ﬁ gure 21 and ﬁ gure 22. Natural gas burner à...
Page 52 PLACING OF CERAMIC LOG SET Logs: Log no u Log no v Log no w Log no x Log no y Log no z Log no { Log no | Bellﬁ res Installation instructions...
Page 53: Natural Gas
Embers must not be placed next to the pilot light burner Keep the burner oriﬁ ces unblocked! Figure 21: Log set View Bell Medium 3 CF Position natural gas burner PROPANE GAS : Embers must not be placed next to the pilot light burner Keep the burner oriﬁ...
Page 54: Gas Fire Decoration Kits
GAS FIRE DECORATION KITS Fire Proof Material Size Colours Stone Pebbles ½” - 1¼” (12-30 mm) Different Crushed Glass ½” - 1¼” (12-30 mm) Different Stone Pebbles Crushed Glass Bellﬁ res Installation instructions...
Page 55 These decoration kits are only for use in a Bellﬁ res View Bell Medium 3 Centre Fire (CF) gas appliance. The following decoration kits can be installed in the appliance: Direct Vent Gas Fireplace: Bellﬁ res View Bell Medium 3 CF Fire Proof Material Size...
Page 56 GAS FIRE DECORATION KITS This instruction describes the replacement of the original log set to a decoration kit of pebbles or glass. WARNING: The decoration kit must be installed by a qualiﬁ ed service technician. 1. Turn off the gas supply with the main gas valve to the appliance 2.
Page 57 GAS FIRE DECORATION KITS Stone Pebbles Keep the back row of slots in the grate open. Keep the burner Stone Pebbles must not be placed oriﬁ ces unblocked! in front of the pilot light burner. Crushed Glass Keep the back row of slots in the grate open.
Page 58: Mounting Of Flue Gas Restriction Plate
MOUNTING OF FLUE GAS RESTRICTION PLATE Depending on the length and shape of the concentric ﬂ ue system and the chimney construction, you should, if indicated, ﬁt a restriction plate with a certain width (B) into the ceiling of the combustion chamber. To do this, see the set-up options as listed in ﬁ...
Page 59: Check Overpressure Hatches
CHECK OVERPRESSURE HATCHES Check overpressure hatches There are two overpressure hatches in the ceiling of the combustion chamber (front). IMPORTANT: Check that the hatches are loose, by lifting a little and carefully letting them come down again. Check if the packing under the hatches is sealed. Left overpressure hatch is in the correct Right overpressure hatch is in the correct position.
Page 60: Visual Check Of Gas Flames
VISUAL CHECK OF GAS FLAMES After installation, visually check the gas ﬂ ame. When the ﬁ re is ignited, the ﬂ ames should be short and blue/yellow in colour. These ﬂ ames should gradually increase in height and become more yellow. When all ﬂ ames are yellow, the gas ﬁ re has reached the correct temperature.
Page 61: Annual Maintenance
ANNUAL MAINTENANCE IMPORTANT: It is essential that the appliance, the complete concentric ﬂ ue system (where possible) and the outlet are cleaned and inspected annually by a certiﬁ ed gas technician. The safe operation of the appliance will thus remain guaranteed. Maintenance consists of the following: •...
Page 62: Faults
FAULTS POSSIBLE REASONS Possible reasons for the gas ﬁ re going out are: • The concentric ﬂ ue system is not installed according to one of the methods detailed in Vent Installation. • An incorrect “ﬂ ue gas restriction plate” is ﬁ tted. •...
Page 63: Dismantling / Assembling Of The Glass
DISMANTLING / ASSEMBLING OF THE GLASS WARNING: Do not operate appliance with the glass front removed, cracked or broken. Replacement of the glass should be done by a licensed or qualiﬁ ed service person. Dismantling of the glass: Place paperboard on the chimney breast, under the appliance. This helps prevent damage.
Page 64 DISMANTLING / ASSEMBLING OF THE GLASS • Remove the side panel on the right. • Remove the bottom panel, by pulling it gently to tilt forward and to remove. Prevent damage to the side glasses ! Bellﬁ res Installation instructions...
Page 65 DISMANTLING / ASSEMBLING OF THE GLASS • Unscrew the strip at the front under the • Using a screwdriver, slide the strip a glass. Screws only need a couple of turns! little to the left. • Remove the strip at the front. •...
Page 66 DISMANTLING / ASSEMBLING OF THE GLASS • Lift the glass carefully and pull it • Remove the glass by slanting it forward forwards a little at the bottom. a little at the bottom and taking it out. All fastening strips on the top side remain in position! •...
Page 67 DISMANTLING / ASSEMBLING OF THE GLASS Compression spring position Side glass L/R Side glass compression spring L/R • Make sure that the compression • Side glass compression spring spring (Left and Right) stays in the (Left and Right). correct position. Assembling of the glasses: The assembly of the glass takes place in reverse order.
Page 68: Diagram Electricity And Gas
DIAGRAM ELECTRICITY AND GAS Double burner: : Perforation pattern “Centre Fire” double burner. Gas pipe “Rear burner” “Rear burner” Gas pipe “Front burner” 8 Wire “Front burner” Motor- connecting knob cable Pilot light Thermocouple Gas supply connection REGULATOR BLOCK Pilot light gas pipe “black”...
Page 69: Dimensions
DIMENSIONS VIEW BELL MEDIUM 3 - Hidden Door Bellﬁ res Installation instructions...
Page 70: Operating Unit
OPERATING UNIT 3.2” 9.7” +14” Dimensions in inches Bellﬁ res Installation instructions...
Page 71: Technical Details
TECHNICAL DETAILS APPLIANCE RATINGS View Bell Medium 3 CF (Centre ﬁ re) Natural gas Propane Thermal efﬁ ciency 83.2 84.2 Annual ﬁ replace 77.8 79.0 efﬁ ciency (P4) Input maximum Btu/hr 40,000 32,000 Input minimum Btu/hr 11,600 8,900 in. w.c.
Page 72: Replacement Part List
REPLACEMENT PART LIST When requesting service or ordering replacement parts, please quote the model type and serial number. All parts listed in this manual may be ordered from a Bellﬁ res dealer. Article no Description 334987 Main burner “Centre Fire” 827 x 130 mm Natural gas / Propane Natural gas: 1x Ø12.0 mm front + 1x Ø12.0 mm rear +corner...
Page 73 REPLACEMENT PART LIST Article no Description 326055 Nut; Ø8 mm, compression elbow main burner 326054 Olive; Ø8 mm, compression elbow main burner 334767 Glass View Bell Medium 3 front (1007 x 467 x 4 mm) 333227 Glass View Bell Medium 3 side (328 x 467 x 4 mm) 301669 Tube ceramic glue 301593...
Page 74 Appliance Log set Embers with Vermiculite no 4 Log no Chips of Glow-effect black wood set Anthracite ﬁ ltered 3 pieces Bag: 125 gr. Bag: 50 gr. Art. no: xxxxxx 301863 332583 331357 331358 331359 331360 331361 331362 331363 331364 View Bell Medium 3 I 332584...
Page 75: Propane Conversion Kit
PROPANE CONVERSION KIT A propane conversion kit is supplied with this appliance. For safe use of this kit, refer to the installation instructions included with the propane conversion kit. This conversion kit is only for use in the Bellﬁ res gas appliance model stated on the front page of this manual and also stated on the included propane conversion kit and must only be used when the gas type for this appliance is changed from natural gas to propane.
Page 76: Warranty Terms
WARRANTY TERMS Warranty terms Interfocos B.V. develops and manufactures all Bellﬁ res hearths to the highest possible quality standards. All Bellﬁ res hearths (product) are warranted against defects in material and workmanship by Interfocos B.V, subject to the following conditions. Article 1: Warranty 1.1.
Page 77 WARRANTY TERMS Article 6: Warranty Limitations 6.1. Limited Lifetime Warranty on Body and Main Burner: The body and main burner of the Bellﬁ res hearth are warranted against defects in construction, materials or workmanship, during the period in which the product is owned by the original owner and installed in the original installation location.
Page 78 Installation instructions Bellﬁ res...
Page 80 FOR YOUR BELLFIRES DEALER VISIT www.neeﬁ replaces.ca www.neefoyers.ca Serial number: Production date: 02 - 010715 - 337337...
