RealPresence Capture Server Connection Methods

The following connection methods are supported for dialing a RealPresence Capture Server.
Capture Server
Type
Capture Server If the RealPresence Group system is not registered to
system the gatekeeper or to a SIP server, dial the
RealPresence Capture Server IP address.
If the RealPresence Group system is registered to the
gatekeeper, dial the RealPresence Capture Server
E.164 extension for H.323.
If the RealPresence Group system is registered to a
SIP server, dial the RealPresence Capture Server SIP
address.
VRR For H.323 calls:
[RealPresence Capture Server IP]##[VRR number]
or
[RealPresence Capture Server E.164 prefix][VRR
number]
For SIP calls:
[VRR number]@[RealPresence Capture Server IP]
or
[SIP peer prefix][VRR number]

RealPresence Capture Server TVUI Interface

When you establish a connection to a RealPresence Capture Server, the TV Interface (TVUI) with buttons
and far-end controls appear, as shown in the next graphic. Unless the administrator for the RealPresence
Capture Server has disabled the Start Recording Immediately option, the recording starts immediately
after the TVUI opens.
Polycom, Inc.
Connection Method Example
10.11.12.13
1234
CS123
If the RealPresence Capture
Server IP is 11.12.13.14 and the
VRR number is 4096,dial
11.12.13.14##4096.
If the RealPresence Capture
Server E.164 prefix is 8888 and the
VRR number is 4096, dial
88884096.
If the RealPresence Capture
Server IP is 11.12.13.14 and the
VRR number is 4096, dial
4096@11.12.13.14.
If the SIP peer prefix of the
RealPresence Capture Server is
8888 and the VRR number is 4096,
dial 88884096.
