Olivetti d-color MF1600 Service Manual page 169

Jam Release Method
Fuser Unit Part [Paper feeding jam and paper eject jam]
The fuser unit is extremely hot. Be careful not to touch it. If the
fuser unit is hot, do not try yourself to clear paper but wait until the
fuser unit becomes cool.
(1) Raise the fuser lock lever (two blue places) in the direction of the arrow.
(2) Hold the handle and take the fuser out, put it on a flat table.
(3) Draw the jammed paper out slowly in the direction of the arrow, while pressing the lever
of the fuser (blue) in the direction of the arrow.
Y108500-4
Possible to get burned.
Handle
Fuser lock lever (blue)
Release lever (blue)
Service Manual
Fuser lock lever (blue)
Release lever (blue)
169
