CLEANINg LED HEAD
If there appear line breaks or white lines, or the letters and characters are blurred, please clean
your LED head.
(1) Switch off the power supply.
(2) Lift the scanner.
(3) Press OPEN button and open the top cover.
The fuser unit is extremely hot. Do not touch it.
(4) Lightly wipe the lens (4 points) of the LED head with soft tissues.
Note! Do not use solvents as methyl alcohol or thinner, as they might cause damage to the
LED head.
(5) Close the top cover.
(6) Lower the scanner.
Y108500-4
I O
Personal injuries may occur.
OPEN button
LED head
