Olivetti d-color MF1600 Service Manual page 105

4361110x Board-Assy PUCU
43420301 Stay-Guide-L Assy
23mm
43422201 Stay-Guide-R Assy
Y108500-4
OR-board-M32
After palish the terminals to luster with BEMCOT M-3 Tetfa
(C-9300) is soaked cotton swab a little (Class:S).
and it coated on terminals. (32 places)
Flange contact area
EM-30L ClassB
Service Manual
Class S
Flange contact area
EM-30L ClassB
23mm
105
