9. To obtain a better view of the Math instantaneous power
waveform, you can use the following oscilloscope functions:
H From the Math menu, push the Position option button and
H From the Math menu, push the Vertical Scale option button
H Turn the SEC/DIV knob to adjust the horizontal scale
H Push the CH 1 MENU and CH 2 MENU buttons to remove

Taking Cursor Measurements

You can use the cursors to quickly take time and amplitude
measurements on a waveform.

Measuring Ring Frequency and Amplitude

To measure the ring frequency at the rising edge of a signal, follow
these steps:
1. Push the CURSOR button to see the Cursor Menu.
2. Push Type
3. Push Source
4. Push the Cursor 1 option button.
5. Turn the multipurpose knob to place a cursor on the first peak of
the ring.
TPS2000 Series Digital Oscilloscope User Manual
turn the multipurpose knob to adjust the vertical position
and turn the multipurpose knob to adjust the vertical scale
the channel waveforms from the display
Time.
CH1.
Application Examples
4- 13
