Oscilloscope Specifications (Cont.)
Measurements
Cursors
Automatic
Measurements
Oscilloscope General Specifications
Display
Display Type
Display Resolution
Display Brightness
Display Contrast
Backlight Intensity, Backlight Intensity,
typical*
Probe Compensator Output
Output Voltage, typical
Frequency, typical
Power Source
Source Voltage of the
Oscilloscope AC
Adaptor
Power Consumption
* Adjustable through the Display menu.
TPS2000 Series Digital Oscilloscope User Manual
Amplitude difference between cursors (∆V, ∆A, or ∆VA)
Time difference between cursors (∆t)
Reciprocal of ∆t in Hertz (1/∆t)
Frequency, Period, Mean, Pk-Pk, Cycle RMS, Min, Max, Rise
Time, Fall Time, Pos Width, Neg Width
5.7 in. (145 mm) diagonal liquid crystal
320 horizontal by 240 vertical pixels
Adjustable
Adjustable, temperature compensated
2
60 to 100 cd/m 60 to 100 cd/m
5 V ±10% into ≥ 1 MΩ load
1 kHz
90 to 264 VAC
RMS
Less than 30 W
Appendix A: Specifications
from 45 Hz through 66 Hz
A- 11
