The option for voltage and current probes is different: Attenuation or
Scale.
Probe options
Voltage
Current
Back
Knobs
VERTICAL POSITION Knobs. Use the VERTICAL POSITION knobs to
move the channel waveforms up or down on the screen.
VOLTS/DIV Knobs. Use the VOLTS/DIV knobs to control how the
oscilloscope amplifies or attenuates the source signal of channel
waveforms. When you turn a VOLTS/DIV knob, the oscilloscope
increases or decreases the vertical size of the waveform on the
screen.
Vertical Measurement Overrange (Clipping). Waveforms that extend
beyond the screen (overrange) and display a "?" in the measurement
readout indicates an invalid value. Adjust the vertical scaling to
ensure the readout is valid.
TPS2000 Series Digital Oscilloscope User Manual
Settings
1X
Attenuation
10X
20X
50X
100X
500X
1000X
5 V/A
Scale
1 V/A
200 mV/A
100 mV/A
50 mV/A
20 mV/A
10 mV/A
1 mV/A
Comments
Set to match the attenuation factor
of the voltage probe to ensure
correct vertical readouts
Set to match the scale of the
current probe to ensure correct
vertical readouts
Returns to the previous menu
Reference
9- 53
