Getting Started

Battery Packs

The oscilloscope can accommodate two TPSBAT battery packs. The
product includes one battery pack that is not installed when shipped.
The amount of time you can operate the oscilloscope with battery
packs depends on the oscilloscope model.
Oscilloscope
2 channel
4 channel
NOTE. A message displays when there are approximately 10 minutes
of operating time left on the battery packs.
For details on how to use, charge, calibrate, and replace battery
packs, refer to Managing TPSBAT Battery Packs on page 8- - 1. For
example, battery packs need to be calibrated to accurately report
available operating time.
To install battery packs, follow these steps:
1. Press the battery compartment door latch on the the right side
panel and open the battery compartment.
1- 8
Amount of time to operate
5.5 hours on one battery pack, 11 hours on two
4.5 hours on one battery pack, 9 hours on two
TPS2000 Series Digital Oscilloscope User Manual
